800509
Drain Valve
Bendix
UNAVAILABLE
FINAL SALE. No returns or exchanges.
This truck part is made by Bendix. We guarantee that all of our parts are from the OEM (original equipment manufacturer), ensuring a proper fit and quality manufacturing.
We honor the warranty provided by the original equipment manufacturer.
DESCRIPTION
The Bendix Drain Valve is a vital component for maintaining the efficiency of your vehicle's air brake system. This automatic drain valve ensures that moisture and contaminants are effectively expelled from the air supply, preventing corrosion and damage to critical brake components. Weighing only 0.7 kg, this valve offers a lightweight solution without sacrificing durability. Its reliable performance is essential for optimal braking efficiency, as accumulated moisture can lead to brake failure and increased wear on the system. The drain valve operates seamlessly, allowing for automatic draining without manual intervention, which translates to lower maintenance efforts for fleet operators. By utilizing this drain valve, you ensure that your brake system remains in peak condition, ready to perform when you need it most. Source One Parts Center is your go-to destination for authentic Bendix OEM parts, ensuring you receive components that meet the rigorous demands of commercial trucking.
SPECIFICATIONS
Minimum Operating Temperature
-40 °F (-40 °C)
VMRS
013-010-193: Drain Valve - Automatic
Maximum Operating Temperature
100 °F (38 °C)
Harness Length
13.50 IN
Heater Orientation (CW from SUP Port)
180°
Heater Rating
24V
Supply Port (Top)
3/8-18 NPT (Plugged)
Supply Port (Side)
3/8-18 NPT x 1/4-18 NPT (Adapter)
Heater ON Setting (Cut-in)
45° ± 10° F
Height
71.9 mm (2.83 in)
Harmonized System (HS) Code
848140,848180
Heater OFF Setting (Cut-out)
85° ± 10° F
Width
89.7 mm (3.53 in)
Length
93.3 mm (3.68 in)
Connector Type
Metri-Pack 280 Series 2-Way Sealed Connector (Male)
Country of Origin
Mexico
Thread Sealant
No Sealant
Mounting
Top Mount
Cautionary Note(s)
When mounted, the exhaust must point down toward the road
Heater
Yes
Weight
1.5 lb
