$224.95
$269.94
This truck part is made by Bendix. We guarantee that all of our parts are from the OEM (original equipment manufacturer), ensuring a proper fit and quality manufacturing.
We honor the warranty provided by the original equipment manufacturer.
DESCRIPTION
The Pressure Proportioning Valve is essential for maintaining balanced braking performance across all wheels, particularly in heavy-duty applications. This valve regulates the brake pressure delivered to the rear wheels, ensuring optimal performance during different loading conditions. Weighing 0.4 kg, it is lightweight yet robust, designed to withstand the demanding environments of commercial trucking. Manufactured with precision, this valve enhances vehicle control and safety by preventing wheel lock-up and ensuring that braking force is distributed evenly. This is crucial for maintaining stability and control during braking maneuvers. For top-quality Bendix OEM parts that ensure your vehicle operates at peak performance, Source One Parts Center is the best place to shop, providing unmatched reliability and selection.
SPECIFICATIONS
Minimum Operating Temperature
-40 °F (-40 °C)
VMRS
013-010-010: Limiter Valve - Air
Control Port
1/4-18 NPT
Height
100.6 mm (3.96 in)
Maximum Operating Temperature
200 °F (93 °C)
Delivery Port 1
3/8-18 NPT
Delivery Port 2
3/8-18 NPT
Supply Port
3/8-18 NPT
Limiting Ratio
50% Limited Delivery
Width
63.5 mm (2.5 in)
Length
77.2 mm (3.04 in)
Harmonized System (HS) Code
848120
Delivery Port Orientation (CW from Mounting)
90° / 270°
Country of Origin
Mexico
Exhaust Port
Open
Application
Standard
Mounting
Ø .34 IN (2x)
Weight
0.95 lb
