455041C92
CHAMBER, BRAKE 24"
Navistar International®
BACK ORDERED
Please contact us for information on lead time
$63.95
$76.74
This truck part is made by Navistar International®. We guarantee that all of our parts are from the OEM (original equipment manufacturer), ensuring a proper fit and quality manufacturing.
We honor the warranty provided by the original equipment manufacturer.
SPECIFICATIONS
OEM Description
CHAMBER, BRAKE 24"
Weight
8.624 lbs
BILL OF MATERIALS
| Name | Quantity | Part Number |
|---|---|---|
| PLUG | 1 | 444819 |
| BOLT, BRAKE CHAMBER CLAMP | 2 | 875770R1 |
| CLAMP, BRAKE CHAMBER W&BOLTS | 1 | 875771R91 |
| DIAPHRAGM, BRAKE CHAMBER TYPE 24 | 1 | 871933R1 |
| ROD,BRK CHAMBER PUSH | 1 | 870632R1 |
| SPRING, BRAKE CHAMBER PUSH ROD | 1 | 875764R1 |
| RETAINER, SPRING BRAKE CHAMBER | 1 | 875767R1 |
RECOMMENDED PARTS
* This information is provided as is and may be out of date. Please contact us or the manufacturer to verify warranty
coverage.
