3867439C94
HOOD ASSEMBLY AS PURCHASED 120 INCH BBC STANDARD
Navistar International®
BACK ORDERED
Please contact us for information on lead time
$3,099.95
$3,719.94
This is an oversize product. Additional shipping fees may apply.
This truck part is made by Navistar International®. We guarantee that all of our parts are from the OEM (original equipment manufacturer), ensuring a proper fit and quality manufacturing.
We honor the warranty provided by the original equipment manufacturer.
SPECIFICATIONS
OEM Description
HOOD ASSEMBLY AS PURCHASED 120 INCH BBC STANDARD
Weight
422.88 lbs
BILL OF MATERIALS
| Name | Quantity | Part Number |
|---|---|---|
| PANEL HOOD OUTER ASSEMBLY 120 BBC | 1 | 3528736C4 |
| BAR, HOOD PIVOT MOUNTING ASSEMBLY | 1 | 3557804C2 |
| WASHER, FLAT | 10 | 25724R1 |
| WASHER, FLAT | 10 | 25553R1 |
| NUT, LOCK | 4 | 9413979 |
| BOLT 3/8-16UNC X 1.25" TYPE 8 PHC | 6 | 26311R1 |
| WASHER, LOCK ZINC PLATED 3/8" | 6 | 120382 |
| NUT, SPEED "U" 5/16" UNC | 18 | 1517493C1 |
| REINFORCEMENT HOOD SIDE, L | 1 | 3530260C4 |
| REINFORCEMENT, HOOD SIDE, R | 1 | 3530261C5 |
| REINFORCEMENT, UPPER CENTER HOOD | 1 | 3524257C3 |
| HOUSING, HEAD LIGHT LEFT | 1 | 3530264C3 |
| HOUSING, HEAD LIGHT RIGHT | 1 | 3530265C3 |
| REINFORCEMENT ASSEMBLY HOOD REAR L | 1 | 3524260C2 |
| REINFORCEMENT ASSEMBLY HOOD REAR R | 1 | 3543969C3 |
| REINFORCEMENT ASSEMBLY, FRONT | 1 | 3530259C2 |
RECOMMENDED PARTS
* This information is provided as is and may be out of date. Please contact us or the manufacturer to verify warranty
coverage.
