AS79960
SPRING-AIR, GRANNING
Kenworth®
AVAILABLE
More than 10 are currently available
Ships within 3-4 business days
$159.99
$191.99
This truck part is made by Kenworth®. We guarantee that all of our parts are from the OEM (original equipment manufacturer), ensuring a proper fit and quality manufacturing. We make it easy to buy truck parts online.
We honor the warranty provided by the original equipment manufacturer.
DESCRIPTION
This part is designed to bolster the suspension system, ensuring reduced vibration and enhanced stability. Its durable construction allows for reliable performance, making it suitable for vehicles needing high-quality suspension support. The focus on compatibility and resilience makes it a crucial component for those seeking to enhance their ride quality.
SPECIFICATIONS
VMRS Code
016-008-001
OEM Part Number
AS79960-090R
Features
Chemically Formulated Vulcanized Material Withstands Ozone Effects
Made With a Unique Fabric Material That Has a Higher Burst Rate for Longer Life
Optimized wall thickness for better fatigue life
100% Leak Tested
Made With a Unique Fabric Material That Has a Higher Burst Rate for Longer Life
Optimized wall thickness for better fatigue life
100% Leak Tested
Diameter (in)
Diameter (in): 12.8
Bellows No.
FT 330-29
OEM Cross Reference
Granning: 8221, 702932-01
Load at 100 psi (lb)
Load at 100 psi (lb): 6800
Load at 80 psi (lb)
Load at 80 psi (lb): 5400
Max Height (in)
Max Height (in): 18.9
Min Height (in)
Min Height (in): 4.5
Ride Height (in)
Ride Height (in): 12
Weight (lb)
Weight (lb): 14.146
