5011190R91
OVERHAUL KIT, STAGE 3 I308 530HT
Navistar International®
BACK ORDERED
Please contact us for information on lead time
This is an oversize product. Additional shipping fees may apply.
This truck part is made by Navistar International®. We guarantee that all of our parts are from the OEM (original equipment manufacturer), ensuring a proper fit and quality manufacturing.
We honor the warranty provided by the original equipment manufacturer.
SPECIFICATIONS
Kits
(1.00) KIT, ENGINE OVERHAUL ,(I308-530); (1.00) HEAD ASSEMBLY CYLINDER REMANUFACTURED MY00-03 DT; (1.00) THERMOSTAT; (1.00) PUMP ASSEMBLY WATER; (20.00) BOLT CYLINDER HEAD; (12.00) BOLT CONNECTING ROD; (1.00) KIT TURBOCHARGER REMANUFACTURED; (1.00) KIT, HIGH PRESSURE PUMP Y 7.0CC; (6.00) KIT, INJECTOR, BN I308, W/SEALS; (1.00) KIT, OIL COOLER; (12.00) GUIDE VALVE LIFTER; (4.00) STUD, TURBOCHARGER ADAPTER; (12.00) BOLT M12 X 1.75MM X 35MM;
Engine Platform
I308 2000 DT466/HT530
OEM Description
OVERHAUL KIT, STAGE 3 I308 530HT
Weight
462.0044 lbs
BILL OF MATERIALS
| Name | Quantity | Part Number |
|---|---|---|
| GUIDE VALVE LIFTER | 12 | 1813892C1 |
| KIT, ENGINE OVERHAUL ,(I308-530) | 1 | 1894140C92 |
| INJECTOR,KIT, INJECTOR, BN I30 | 6 | 2593597C92 |
| Renewed DT Cylinder Head Assembly 2000-2003 | 1 | 2599992C92 |
| KIT TURBOCHARGER REMANUFACTURED | 1 | 4307248R91 |
| BOLT M12 X 1.75MM X 35MM | 12 | 1817830C1 |
| STUD, TURBOCHARGER ADAPTER | 4 | 1821642C3 |
| BOLT CYLINDER HEAD | 20 | 1824954C3 |
| Assembly, Thermostat | 1 | 1830256C93 |
| PUMP ASSEMBLY WATER | 1 | 1830606C95 |
| KIT, OIL COOLER | 1 | 1841741C92 |
| KIT, HIGH PRESSURE PUMP Y 7.0CC | 1 | 1842723C91 |
| BOLT CONNECTING ROD | 12 | 1873884C2 |
RECOMMENDED PARTS
* This information is provided as is and may be out of date. Please contact us or the manufacturer to verify warranty
coverage.
