3508880C91
TRANSMISSION SPICER (TTC) LLPSO150-9A 13MCB SP PSO150-9A WITH HOUSING
Navistar International®
BACK ORDERED
Please contact us for information on lead time
$6,999.95
$8,399.94
This truck part is made by Navistar International®. We guarantee that all of our parts are from the OEM (original equipment manufacturer), ensuring a proper fit and quality manufacturing.
We honor the warranty provided by the original equipment manufacturer.
SPECIFICATIONS
VMRS
026-012-000
OEM Description
TRANSMISSION SPICER (TTC) LLPSO150-9A 13MCB SP PSO150-9A WITH HOUSING
BILL OF MATERIALS
| Name | Quantity | Part Number |
|---|---|---|
| GEAR MAIN SHAFT 2ND AND 6TH 58T | 1 | 1668536C1 |
| TUBE, DISCHARGE | 1 | 1699084C1 |
| PLATE, MOUNTING INTERNAL PUMP | 1 | 1699081C1 |
| VALVE, OIL BYPASS | 1 | 1699086C91 |
| PUMP, TRANSFER CASE OIL | 1 | 1699085C91 |
| GEAR MAIN SHAFT 1ST 58T | 1 | 1668535C1 |
| PLUG OPTILUBE PASSAGE 3/8" | 1 | 2501659C1 |
| VALVE, RETURN | 1 | 1669363C91 |
| GASKET SHIFT VALVE | 1 | 1669368C1 |
| BOLT 7/16" X 2 1/4" | 2 | 24852R1 |
| FITTING, ELBOW TUBING | 2 | 1694488C1 |
| ADAPTER CONTROL LEVER HOUSING | 1 | 1669425C1 |
| ELBOW, PIPE | 1 | 1669365C1 |
| GEAR MAIN SHAFT REVERSE | 1 | 1668503C1 |
| PIN NEUTRAL START SWITCH | 3 | 1669369C91 |
| PIN NEUTRAL START SWITCH | 3 | 1699975C1 |
| PLUG, EXPANSION | 2 | 1669419C1 |
| SPRING, POPPET 1ST AND REVERSE | 2 | 1694691C1 |
| PIN SELECT PLUNGER 1ST AND REVERSE | 2 | 596402C1 |
| SWITCH, BACKUP LIGHT 3/4"-16 UNF | 1 | 1646970C1 |
| PLATE, COVER SHIFT HOUSING | 1 | 1669418C1 |
| BOLT, 7/16 X 1 PHC P/T TYPE 8 | 2 | 26314R1 |
| INTERLOCK SHIFTER RAIL | 1 | 1669370C1 |
| SHAFT, MAIN WITH RING | 1 | 1669351C91 |
| SPRING, SHIFT BAR POPPET | 3 | 1696901C1 |
| BALL, 5/8 GRADE 25 METAL | 3 | 17020R1 |
| BAR ASSEMBLY SHIFT 1ST AND REVERSE W/YOKE | 1 | 1668549C2 |
| BAR ASSEMBLY SHIFT 2ND AND 3RD W/YOKE | 1 | 1668550C2 |
| BAR ASSEMBLY SHIFT 4TH AND 5TH WITH YOKE | 1 | 1669409C91 |
| YOKE, SHIFT OVER DRIVE W/PINS | 1 | 1677228C91 |
| RING, SNAP .281 EXT RECT SECT R | 1 | 128487C1 |
| RING, SNAP | 1 | 1668543C1 |
| BOLT, OVER DRIVE MOUNTING BRACKET | 2 | 1696296C1 |
| BRACKET-OVER DRIVE SHIFT FORK | 1 | 2592256C91 |
| BRACKET-OVER DRIVE SHIFT FORK | 1 | 1697285C1 |
| RING, SNAP WIPER MOTOR .338 EXT | 2 | 213262R1 |
| CASE, TRANSFER | 1 | 1669355C91 |
| BAR ASSEMBLY SHIFT RANGE W/YOKE AND CLIPS | 1 | 1694328C91 |
| CLIP SHIFT YOKE | 2 | 1694519C1 |
| COVER, REAR BEARING COUNTER SHAFT | 2 | 1668545C2 |
| STUD, FLYWHEEL HOUSING | 2 | 1669429C1 |
| FITTING, ELBOW AUXILIARY SHIFT HOUSING | 2 | 3290027R1 |
| RING, "O" CLASS 5 1/2" X 5/8" | 1 | 370920R1 |
| PISTON, RANGE SHIFT VALVE | 1 | 1669306C2 |
| NUT, LOCK 7/16" UNF | 1 | 2506644C1 |
| HOUSING, RANGE PISTON | 1 | 1669300C91 |
| RETAINER, MAIN SHAFT REAR BEARING | 1 | 1669352C93 |
| BOLT 3/8-16UNC X 1.25" TYPE 8 PHC | 4 | 26311R1 |
| PLUG INTERLOCK HOLE | 2 | 3290096R1 |
| PLUG SPEEDOMETER GEAR HOLE | 1 | 30443V |
| SEAL, OIL DRIVE GEAR BEARING | 1 | 1668500C1 |
| NUT, HEXAGON TYPE 8 7/16" UNF | 4 | 25525R1 |
| BEARING, BALL | 2 | 636826R91 |
| BRACKET, MOUNTING AUXILIARY SHIFT LEVER | 1 | 1669305C1 |
| BOLT PREVAILING TORQUE 7/16-14UN | 6 | 27438R1 |
| GASKET SHIFT LEVER HOUSING | 1 | 1669367C1 |
| KEY FRONT COUNTER SHAFT GEAR | 2 | 1669372C2 |
| KEY MIDDLE COUNTER SHAFT GEAR | 2 | 1669371C2 |
| KEY REAR COUNTER SHAFT GEAR | 2 | 1669373C2 |
| SHAFT, COUNTER | 2 | 1694327C1 |
| GEAR COUNTER SHAFT 5TH AND 9TH 65T | 2 | 1685526C1 |
| RING, SNAP COUNTER SHAFT THRUST GEAR | 2 | 1668541C1 |
| RING, SNAP COUNTER SHAFT THRUST GEAR | 2 | 1668540C1 |
| GEAR COUNTER SHAFT 5TH AND 9TH 46T | 2 | 1668526C1 |
| GEAR COUNTER SHAFT 3RD AND 7TH 39T | 2 | 1693916C1 |
| GEAR COUNTER SHAFT POWER TAKE-OFF | 2 | 1693918C1 |
| GEAR COUNTER SHAFT 2ND AND 6TH 37T | 2 | 1668531C1 |
| GEAR COUNTER SHAFT 1ST 24T | 2 | 1668530C1 |
| BEARING, BALL | 1 | 1669362C1 |
| RING, THRUST COUNTER SHAFT | 2 | 1668539C1 |
| BEARING, CONE | 2 | 1662973C1 |
| PLATE RETAINING COUNTER SHAFT | 1 | 1669308C1 |
| BOLT 3/8" X 7/8" | 6 | 27768R1 |
| GEAR COUNTER SHAFT REVERSE 21T | 2 | 1668504C1 |
| O-RING | 1 | 615901C1 |
| GEAR COUNTER SHAFT INTERMEDIATE REVERSE | 2 | 1668508C1 |
| SHAFT, COUNTER AUXILIARY | 2 | 1699435C1 |
| RING, THRUST | 1 | 1668510C1 |
| GEAR DRIVE HIGH RANGE | 1 | 1668506C1 |
| RACE, OUTER NEEDLE BEARING SYNCRONIZER | 1 | 1668509C1 |
| GEAR DRIVE HIGH RANGE | 1 | 1668505C1 |
| SHAFT, MAIN AUXILIARY | 1 | 1668511C1 |
| BEARING NEEDLE S | 2 | 1669374C91 |
| BEARING NEEDLE S | 2 | 1669303C1 |
| GEAR MAIN SHAFT 4TH AND 8TH 38T | 1 | 1668533C1 |
| GEAR OUTPUT LOW RANGE | 1 | 1668507C1 |
| WASHER, THRUST OUTPUT SHAFT | 1 | 1668514C1 |
| BEARING, ROLLER AND SPACER ASSEMBLY | 1 | 1677093C91 |
| WASHER, COMPANION FLANGE NUT | 1 | 456426C1 |
| NUT MAIN SHAFT BEARING | 1 | 591066C1 |
| COLLAR, CLUTCH MAIN SHAFT | 2 | 1668524C1 |
| RETAINER, MAIN DRIVE GEAR BEARING | 1 | 1669353C91 |
| SEAL, OIL DRIVE GEAR BEARING W/SLEEVE | 1 | 1657064C91 |
| HOUSING ,TRANS CLUTCH | 1 | 1699157C91 |
| BOLT 1/2" X 1 1/2" | 16 | 26318R1 |
| COVER, HAND HOLE CLUTCH HOUSING | 1 | 697726R2 |
| BUSHING, CLUTCH RELAY LEVER UPPER HOUSING | 4 | 579515C1 |
| TROUGH, OIL | 2 | 1669426C1 |
| STANDARD PART /NOT ASSIGNED BOLT, HEXAGON HEAD PREVAIL TRQ 3/8-16UNC X 1/2, | 4 | 27431R1 |
| GEAR MAIN SHAFT 4TH AND 5TH | 1 | 1685527C1 |
| GUIDE, SHIFT BAR SUPPORT FRONT | 2 | 596421C1 |
| CLAMP, TUBE | 1 | 299399C1 |
| CLAMP, CABLE 1" I.D. X 13/32" | 1 | 406381C1 |
| LOOM, CONVOLUTED ELECTRICAL WIRE | 1 | 445171C1 |
| RING, "O" | 12 | 1697789C1 |
| BOLT 3/8" X 1 1/2" | 4 | 26312R1 |
| CASE TRANS AUXILIARY S | 1 | 1668554C1 |
| RETAINER M/D GEAR S | 1 | 1668553C1 |
| RETAINER, MAIN SHAFT REAR BEARING | 1 | 1669352C92 |
| RETAINER, MANUAL SHIFT REAR BEARING | 1 | 1668499C1 |
| GEAR MAIN SHAFT DRIVE | 1 | 1668557C1 |
| CASE, TRANSMISSION | 1 | 2500406C91 |
| GASKET ELIMINATOR 50 ML 515 | 1 | PTX51531 |
| GASKET ELIMINATOR 50 ML 515 | 1 | 474517C2 |
| COVER TRANSFER CASE OIL OUTLET | 1 | 1699076C1 |
| GASKET TRANSFER CASE | 1 | 1699074C1 |
| FORK, SHIFT OVER DRIVE W/PINS AND | 1 | 1669366C92 |
| BOLT SPECIAL NYLON PATCH | 8 | 467151C1 |
| CUP, BEARING | 4 | FP25520 |
| CUP, BEARING | 4 | ST987 |
| PIN, DOWEL | 4 | 1669417C1 |
| COVER POWER TAKE- OFF OPENING | 1 | 13156H |
| BOLT APENTURE COVER POWER TAKE-OFF | 6 | 71769C1 |
| PLUG, MAGNETIC | 1 | 318724C1 |
| GEAR MAIN SHAFT 3RD AND 7TH 44T | 1 | 1668534C1 |
| PLUG PRESSURE PORTAL TRANSFER CASE | 1 | 1699075C1 |
| PIN TRANSFER CASE ALIGNMENT | 2 | 1699077C1 |
| PLUG, MAGNETIC DRAIN 1" | 1 | 1669319C1 |
| COVER POWER TAKE-OFF OPENING | 1 | 332603C1 |
| BOLT, POWER TAKE-OFF APERTURE COVER | 8 | 441366C1 |
| MAGNET, CERAMIC CASE | 3 | 596399C1 |
CROSS REFERENCES
- DANA 301711-1
- DANA 301711-1
- TRANSTE 301711-1
- TRANSTE 301711-1
RECOMMENDED PARTS
* This information is provided as is and may be out of date. Please contact us or the manufacturer to verify warranty
coverage.
