3604694C91
TRANSMISSION, WITH HOUSING RTLOF-16918B STANDARD W/LUBPMP,IRON CLHSG, EXT
Navistar International®
BACK ORDERED
Please contact us for information on lead time
This truck part is made by Navistar International®. We guarantee that all of our parts are from the OEM (original equipment manufacturer), ensuring a proper fit and quality manufacturing.
We honor the warranty provided by the original equipment manufacturer.
SPECIFICATIONS
OEM Description
TRANSMISSION, W/HOUSING RTLOF-16918B STANDARD W/LUBPMP,IRON CLHSG, EXT
BILL OF MATERIALS
| Name | Quantity | Part Number |
|---|---|---|
| BOLT W/LOCK WASHER | 4 | FULX8C604 |
| GASKET SHIFT TOWER | 1 | FUL4305294 |
| HOUSING, SHIFT BAR | 1 | 2588392C91 |
| GASKET SHIFT BAR HOUSING COVER | 1 | FUL4302676 |
| BREATHER TRANSMISSION | 1 | FUL4304602 |
| PLUG SPECIAL | 1 | FULX12603 |
| BOLT W/LOCK WASHER | 1 | FULX8L609 |
| GASKET NEUTRAL SWITCH OPENING PLUG | 1 | FUL17179 |
| FITTING, PIPE PLUG SOCKET HEAD 3/4" | 1 | FUL4303655 |
| BOLT W/LOCK WASHER 3/8" X 1 1/2" UNC | 2 | FULX8L602 |
| PIN W/GROOVE INTERMEDIATE PINION | 1 | FUL15899 |
| GASKET SHIFT BAR HOUSING COVER | 1 | FUL15900 |
| FITTING, PIPE PLUG SOCKET HEAD 9/16" | 1 | FUL4303656 |
| SPRING, SHIFT LEVER | 3 | FUL15918 |
| HOUSING, SHIFT BAR | 1 | FULS2911 |
| FITTING, COMPRESSION FLEX TUBE 1/8" NPTF X 5/32" TUBE | 3 | FUL85003 |
| BEARING, ROLLER | 4 | FUL4301851 |
| ROTOR, SPEEDOMETER | 1 | FULS2501 |
| O-RING | 1 | FUL5568511 |
| SCREW, SET SHIFT YOKE | 2 | FULX80801M |
| RETAINER, REAR BEARING | 1 | FULS2809 |
| RETAINER, REAR BEARING | 1 | FULA7199 |
| BOLT, REAR HOUSING W/LOCK WASHER 3/8" X 2" UNC | 2 | FULX8L614 |
| BOLT, REAR BEARING COVER W/LOCK WASHER | 4 | FULX8L611 |
| COVER, COUNTER SHAFT REAR BEARING | 2 | FUL4302320 |
| GASKET AUXILIARY COUNTER SHAFT COVER | 2 | FUL4307247 |
| GASKET AUXILIARY COUNTER SHAFT COVER | 2 | FUL4302246 |
| GASKET REAR CASE HOUSING | 1 | FUL14335 |
| HOUSING ,TRANS CASE REAR | 1 | 2588395C91 |
| SLINGER, OIL MAIN DRIVE BEARING | 1 | FUL4304653 |
| BEARING AUXILIARY DRIVE | 1 | FULA6937 |
| RETAINER, AUXILIARY DRIVE GEAR | 1 | FUL4304497 |
| BOLT 3/8" X 1 1/2" UNC | 6 | FULX8680 |
| SPACER | 1 | FUL4304500 |
| WASHER, SPECIAL AUXILIARY DRIVE | 1 | FUL4303185 |
| RING, SNAP MAIN SHAFT | 1 | FUL4301254 |
| SHAFT, ASSEMBLY TRANS MAIN | 1 | 2506640C91 |
| NUT, SPECIAL HEXAGON FLANGE | 1 | FULK4122 |
| NUT, SPECIAL HEXAGON FLANGE | 1 | FUL4302321 |
| RING, SNAP | 2 | FUL4302082 |
| BEARING, BALL | 2 | FUL4302712 |
| SHAFT ,TRANS COUNTER LEFT | 1 | 2506641C91 |
| SHAFT ,TRANS COUNTER RIGHT | 1 | 2506642C91 |
| BEARING, ROLLER | 2 | FUL4304599 |
| RETAINER, COUNTER SHAFT FRONT BEARING | 2 | FUL4304605 |
| BOLT 5/8" X 1 3/4" | 2 | FULX71005 |
| SHAFT, ASSEMBLY INPUT | 1 | 2506508C91 |
| REGULATOR, AIR W/FILTER, | 1 | FULA4740 |
| CASE ASSEMBLY, W/INTEGRAL OIL PUMP | 1 | 2589278C91 |
| PLUG (MULTIPLE PACKAGE 2) | 2 | FUL4304023 |
| TUBE, LUBE (EXTENDED) | 1 | FULA7471 |
| GASKET POWER TAKE- OFF OPENING COVER | 1 | FUL4305310 |
| BOLT W/LOCK WASHER 5/8" X 1 1/4" UNC | 2 | FULX8C412 |
| COVER POWER TAKE- OFF OPENING | 1 | FUL4302809 |
| BOLT, SPECIAL | 8 | FULX8725 |
| GASKET CLUTCH HOUSING | 1 | FUL4308226 |
| GASKET CLUTCH HOUSING | 1 | FUL4305668 |
| BOLT W/LOCK WASHER 5/16" X 1/2" UNC | 4 | FUL239614 |
| BOLT W/LOCK WASHER 5/16" X 1/2" UNC | 4 | FULX8L509 |
| COVER, HAND HOLE CLUTCH HOUSING | 1 | FUL4305230 |
| WASHER, PLAIN | 6 | FULX101005 |
| NUT 5/8" | 6 | FULX11012 |
| RETAINER, MAIN DRIVE GEAR BEARING | 1 | FUL20550 |
| GASKET FRONT BEARING COVER | 1 | FUL14311 |
| BOLT HEXAGON HEAD CAP SCREW WITH WASHER | 4 | FULX8C830 |
| BOLT W/LOCK WASHER | 2 | FULX8C831 |
| BOLT W/LOCK WASHER | 2 | FULX8C822 |
| BOLT HEXAGON HEAD CAP SCREW WITH WASHER | 4 | FULX8C826 |
| COVER POWER TAKE- OFF OPENING | 1 | FUL14575 |
| GASKET POWER TAKE- OFF | 1 | FUL4305309 |
| PIN, DOWEL TRANSFER CASE | 2 | FUL18128 |
| NUT 5/8" | 2 | FULX11005 |
| STUD, FLYWHEEL HOUSING | 2 | FUL14554 |
| PLUG, HEXAGON HEAD 1/2" | 1 | 444705 |
| PLUG, HEXAGON HEAD 1/2" | 1 | FULX12802 |
| WASHER INTERMEDIATE REVERSSE | 4 | FUL4302982 |
| BEARING REVERSE IDLER | 2 | FULA6761 |
| RING, RETAINING | 2 | FUL4303336 |
| VALVE, ASSEMBLY RANGE SLAVE | 1 | 2506547C91 |
| GASKET CONTROL LEVER HOUSING | 1 | FUL19481 |
| BOLT W/LOCK WASHER 1/4" X 1 3/4" UNC | 4 | FULX8C411 |
| HOSE, FLEXIBLE AIR 36" | 2 | FUL55528 |
| PLUG, EXPANSION | 2 | FULX12208 |
| BOLT CAP SCREW 3/8" X 1 1/4" UNC | 1 | FULX8L604 |
| CLAMP, HOSE | 1 | FUL21427 |
| STRAP, SWITCH HARNESS | 1 | FUL21425 |
| BRACKET, SUPPORT HOSE | 1 | FUL21426 |
| CLAMP, HOSE TRIPLE | 1 | FUL21428 |
| HOSE ASSEMBLY | 1 | FUL55527 |
| BOLT, PUMP PORTAL COVER | 5 | FULX8C409 |
| GASKET PUMP PORTAL COVER | 1 | FUL20514 |
| BOLT, SHIFT CYLINDER | 2 | FULX8686 |
| TUBE, SPLITTER LUBE | 1 | FUL4305715 |
| PLUG, EXPANSION | 2 | FUL20224 |
| PIN RANGE SLAVE ACTUATING | 1 | FULA7560 |
| SCREW SELF TAPPING | 2 | FULX13206 |
| SPRING, SHIFT LEVER | 1 | FUL15919 |
RECOMMENDED PARTS
* This information is provided as is and may be out of date. Please contact us or the manufacturer to verify warranty
coverage.
