K072856
Steering Angle Sensor
Bendix
UNAVAILABLE
FINAL SALE. No returns or exchanges.
This truck part is made by Bendix. We guarantee that all of our parts are from the OEM (original equipment manufacturer), ensuring a proper fit and quality manufacturing.
We honor the warranty provided by the original equipment manufacturer.
DESCRIPTION
The Steering Angle Sensor from Bendix is a vital component for enhancing vehicle stability and safety in commercial applications. This sensor provides critical data to the vehicle's stability control systems, helping to prevent skidding and improve handling during turns. Designed for durability, it operates effectively under a wide range of temperatures and conditions, ensuring consistent performance. Its compact design allows for easy installation, making it a practical upgrade for any fleet. When you need genuine Bendix OEM parts, Source One Parts Center is your trusted supplier for high-quality components.
SPECIFICATIONS
Minimum Operating Temperature
-40 °F (-40 °C)
VMRS
015-002-029: Sensor - Steering Wheel Angle
Current (Maximum)
150 mA
Overvoltage
18 Volts
Maximum Operating Temperature
185 °F (85 °C)
CAN Baud Rate
250 Kilobaud
Length
32.6 mm (1.28 in)
Width
72.0 mm (2.83 in)
Operating Voltage Range
8.2 VDC - 16 VDC
Height
85.0 mm (3.35 in)
Harmonized System (HS) Code
854370
Connector Orientation
90°
Connector Type
Bosch 7-Pin Connector (Male)
Cautionary Note(s)
Fastener Torque & Orientation are Critical
Ingress Protection Rating
IP50
Country of Origin
Portugal
Steering Column Shaft Diameter
Ø 24.90 mm
Weight
0.13 lb
