K048055
Yaw Rate Sensor
Bendix
DISCONTINUED
FINAL SALE. No returns or exchanges.
This truck part is made by Bendix. We guarantee that all of our parts are from the OEM (original equipment manufacturer), ensuring a proper fit and quality manufacturing.
We honor the warranty provided by the original equipment manufacturer.
DESCRIPTION
The Yaw Rate Sensor by Bendix is a vital component for advanced braking systems, ensuring optimal stability and control while driving. Manufactured in Hungary, this sensor is designed to provide accurate data on the vehicle's orientation and movement, enabling the braking system to respond effectively to dynamic driving conditions. Its durable construction ensures reliability, even in harsh environments, making it an essential part for enhancing the safety of your commercial vehicle. With straightforward installation and maintenance, this sensor is an excellent investment for fleet operators looking to improve braking performance. For genuine Bendix OEM parts, Source One Parts Center is the best choice, committed to providing quality components for your vehicle.
SPECIFICATIONS
Minimum Operating Temperature
-40 °F (-40 °C)
VMRS
015-012-001: Sensor - Yaw Rate, Electronic Stability Control
Current (Maximum)
130 mA
Maximum Operating Temperature
185 °F (85 °C)
CAN Baud Rate
250 Kilobaud
Height
61.4 mm (2.42 in)
Operating Voltage Range
7 VDC - 18 VDC
Width
70.1 mm (2.76 in)
Length
73.7 mm (2.9 in)
Harmonized System (HS) Code
903180
Connector Type
DIN 72585 4-Way Bayonet Plug Connector (Twist-Lock)
Cautionary Note(s)
Fastener Torque & Vent Orientation are Critical
Country of Origin
Hungary
Ingress Protection Rating
IPX6K / IPX9K
Mounting
M10 x 1.5-6H (2x)
Weight
0.6 lb
