K139376
Four Circuit Prot. Valve
Bendix
UNAVAILABLE
FINAL SALE. No returns or exchanges.
This truck part is made by Bendix. We guarantee that all of our parts are from the OEM (original equipment manufacturer), ensuring a proper fit and quality manufacturing.
We honor the warranty provided by the original equipment manufacturer.
DESCRIPTION
The Bendix Four Circuit Protection Valve is crucial for maintaining the integrity of air disc brake systems in commercial vehicles. This valve features advanced technology designed to manage multiple circuits effectively, ensuring that the braking system operates under optimal conditions. With a compact design and weighing only 1.5 kg (3.31 lbs), it is engineered for easy installation and reliable performance. The valve's advanced features include feedback control and electrical pressure sensing, providing enhanced safety and responsiveness during braking. For fleet operators looking to improve their braking systems, this valve is an essential upgrade. Source One Parts Center is the best place to purchase genuine Bendix OEM parts, ensuring quality and performance for your commercial vehicles.
SPECIFICATIONS
VMRS
013-010-044: Pressure Protection Valve - Air Brake System
Height
130.0 mm (5.12 in)
Width
170.0 mm (6.69 in)
Length
210.0 mm (8.27 in)
Circuit 3 - Open/close pressure [bar]
7.5-0.3/ >=5.5
Circuit 3 - Pressure Limiting [bar]
8.5 +0.0/-0.6
Harmonized System (HS) Code
848120
Circuit 1 - Open/close pressure [bar]
9,0-0.3/ >=7.0
Circuit 2 - Open/close pressure [bar]
9,0-0.3/ >=7.0
Circuit 4 - Open/close pressure [bar]
9,0-0.3/ >=7.0
Bleed-back safety feature
Controlled by Circuit 1
Circuit 1
Feedback with Bypass
Circuit 2
Feedback with Bypass
Circuit 4
Feedback with Bypass
Country of Origin
Hungary
Circuits' supply
Internal series supply from 4 and 1 and 2 to 3
Air Inlet port(s) size
M16x1,5
Circuit 3
Non-feedback with no Bypass
Circuit 1 - Pressure Limiting [bar]
Not included
Circuit 2 - Pressure Limiting [bar]
Not included
Circuit 4 - Pressure Limiting [bar]
Not included
Air Delivery port(s) size
Voss NG12 M22x1,5
With Electrical pressure sensing
Yes
