1308EBA230
Brake Shoe
Bendix
DISCONTINUED
FINAL SALE. No returns or exchanges.
This truck part is made by Bendix. We guarantee that all of our parts are from the OEM (original equipment manufacturer), ensuring a proper fit and quality manufacturing.
We honor the warranty provided by the original equipment manufacturer.
DESCRIPTION
The Brake Shoe is a vital component in Bendix air disc brake systems, engineered to deliver exceptional stopping power and safety. This shoe is made from high-quality stamped steel and features a PermaGuard coating for enhanced durability and resistance to wear. With a net weight of 7.8 pounds, it is designed for optimal performance, ensuring that your braking system operates effectively under various conditions. The shoe's design allows for efficient friction management, which translates to improved braking efficiency and reduced maintenance costs. Fleet operators will appreciate the longevity and reliability this brake shoe provides, making it a smart investment for vehicle safety. For sourcing genuine Bendix OEM parts, including brake shoes, Source One Parts Center is your trusted source, delivering high-quality components that enhance your vehicle's performance.
SPECIFICATIONS
VMRS
013-017-007: Shoe - Brake, Position Not Specified
Shoe Quantity
1
FMSI
1308
Number of Rivets
14
GAWR
23K
Shoe Width
4.0 IN
Harmonized System (HS) Code
870830
Friction
BA230 (Bendix Advanced)
Hardware Included
No
Shoe Coating
PermaGuard
Shoe Material
Stamped Steel
Country of Origin
United States
Drum Size
Ø 15.0 IN
Weight
7.8 lb
