K111347
Front Radar Assembly
Bendix
DISCONTINUED
FINAL SALE. No returns or exchanges.
This truck part is made by Bendix. We guarantee that all of our parts are from the OEM (original equipment manufacturer), ensuring a proper fit and quality manufacturing.
We honor the warranty provided by the original equipment manufacturer.
DESCRIPTION
The Front Radar Assembly from Bendix is a cutting-edge component designed to enhance the safety and performance of your commercial vehicle. This advanced radar system utilizes forward-looking technology to provide comprehensive collision avoidance capabilities that are crucial for drivers operating in busy environments. With a 360° viewing capability, this assembly allows for greater awareness of surroundings, significantly reducing the risk of accidents caused by blind spots. It operates efficiently within a wide temperature range, ensuring reliability in various weather conditions, and is equipped with a sealed connector for robust performance. The radar assembly is specifically designed for applications like the Wingman Advanced, making it an essential addition to modern fleets focused on safety. For those looking to ensure their vehicles are equipped with genuine and reliable parts, Source One Parts Center is your best resource for authentic Bendix OEM parts, ensuring that you receive quality components tailored for your commercial needs.
SPECIFICATIONS
Minimum Operating Temperature
-40 °F (-40 °C)
VMRS
036-001-032: Sensor - Front, Collision Avoidance System
Width
164.0 mm (6.46 in)
Maximum Operating Temperature
185 °F (85 °C)
CAN Baud Rate
250 Kilobaud
Length
32.0 mm (1.26 in)
Harmonized System (HS) Code
852610
Height
95.0 mm (3.74 in)
Product Type
FLR-20
Country of Origin
France
Connector
MCON Interconnection System 10-Way Sealed Connector (Female)
Application
Wingman Advanced
Weight
2.57 lb
