K111348
Front Radar Assembly
Bendix
DISCONTINUED
FINAL SALE. No returns or exchanges.
This truck part is made by Bendix. We guarantee that all of our parts are from the OEM (original equipment manufacturer), ensuring a proper fit and quality manufacturing.
We honor the warranty provided by the original equipment manufacturer.
DESCRIPTION
The Front Radar Assembly from Bendix is an advanced component designed for driver assistance systems, specifically for collision mitigation and warning applications. This forward-looking radar plays a crucial role in enhancing vehicle safety by detecting obstacles and providing real-time feedback to drivers, thereby preventing accidents. Engineered for durability and precision, this radar assembly is capable of operating in various environmental conditions, ensuring consistent performance. Its compact design allows for easy integration into commercial vehicle systems, making it an ideal choice for fleet operators looking to enhance safety features. For genuine Bendix OEM parts, Source One Parts Center is the best place to ensure your vehicles are equipped with the latest safety technologies.
SPECIFICATIONS
Minimum Operating Temperature
-40 °F (-40 °C)
VMRS
036-001-032: Sensor - Front, Collision Avoidance System
Width
164.0 mm (6.46 in)
Maximum Operating Temperature
185 °F (85 °C)
CAN Baud Rate
250 Kilobaud
Length
32.0 mm (1.26 in)
Harmonized System (HS) Code
852610
Height
95.0 mm (3.74 in)
Product Type
FLR-20
Country of Origin
France
Connector
MCON Interconnection System 10-Way Sealed Connector (Female)
Application
Wingman Advanced
Weight
2.99 lb
