K050555
Bracket Assembly
Bendix
UNAVAILABLE
FINAL SALE. No returns or exchanges.
This truck part is made by Bendix. We guarantee that all of our parts are from the OEM (original equipment manufacturer), ensuring a proper fit and quality manufacturing.
We honor the warranty provided by the original equipment manufacturer.
DESCRIPTION
The Bracket Assembly is an essential component in the foundation drum brake system, providing critical support for the braking mechanism in commercial vehicles. This assembly features a robust design with durable nylon bushings for long-lasting performance and reliability. With a gusset angle of 84° CW, it aligns perfectly with other components, ensuring optimal braking efficiency. Weighing 6.4 kg, this assembly is built to withstand the demands of heavy-duty use, making it a reliable choice for fleet operations. Proper installation of this Bracket Assembly enhances your vehicle's braking performance and safety. For top-quality Bendix OEM parts, Source One Parts Center is your go-to source, offering a wide range of reliable components for all your commercial vehicle needs.
SPECIFICATIONS
VMRS
013-017-009: Bracket - Chamber, Position Not Specified
Length (Basic Weld Set)
1.063 IN
Length (Centerline to Centerline) [IN]
15.06
Gusset Angle
40°
Length (Slack Length)
5.50 IN - 6.00 IN
Camshaft Bracket Angle
84° CW
Harmonized System (HS) Code
870830
Arm Style
Full
Inboard Bushing
Nylon
Outboard Bushing
Nylon
Gusset
Single
Country of Origin
United States
Weight
14 lb
