K083403
Bracket Assembly
Bendix
UNAVAILABLE
FINAL SALE. No returns or exchanges.
This truck part is made by Bendix. We guarantee that all of our parts are from the OEM (original equipment manufacturer), ensuring a proper fit and quality manufacturing.
We honor the warranty provided by the original equipment manufacturer.
DESCRIPTION
The Bracket Assembly is meticulously designed to enhance the functionality of your truck's braking system. Featuring a single gusset and full arm style, this part ensures strength and stability during operation. With a length range of 5.50 to 6.00 inches for slack length and a camshaft bracket angle of 70° clockwise, it guarantees correct alignment and efficient performance. Weighing 4.5 kg (9.99 lb), this high-quality assembly is built for longevity, making it an essential component for your commercial vehicle. For genuine Bendix OEM parts, rely on Source One Parts Center to provide you with the best quality and service.
SPECIFICATIONS
VMRS
013-017-009: Bracket - Chamber, Position Not Specified
Length (Basic Weld Set)
1.063 IN
Length (Centerline to Centerline) [IN]
11.50
Gusset Angle
40°
Length (Slack Length)
5.50 IN - 6.00 IN
Camshaft Bracket Angle
70° CW
Harmonized System (HS) Code
870830
Outboard Bushing
Bronze
Arm Style
Full
Inboard Bushing
Nylon
Gusset
Single
Country of Origin
United States
Weight
9.99 lb
