$169.95
$203.94
FINAL SALE. No returns or exchanges.
This truck part is made by Bendix. We guarantee that all of our parts are from the OEM (original equipment manufacturer), ensuring a proper fit and quality manufacturing.
We honor the warranty provided by the original equipment manufacturer.
DESCRIPTION
The Bendix Diaphragm is a critical component of the air chamber system, designed to provide reliable operation and optimal performance in braking applications. Weighing just 0.2 kg, this diaphragm is engineered for durability and efficiency, ensuring that your braking system functions effectively under various conditions. Its robust design allows for smooth operation, helping to maintain consistent braking performance and safety. This diaphragm is essential for ensuring that air pressure is effectively managed within the braking system, contributing to overall vehicle safety. For those in need of genuine Bendix parts, Source One Parts Center is your best source, offering a wide selection of high-quality OEM components.
SPECIFICATIONS
VMRS
013-002-152: Diaphragm - Air Chamber, Rear Axle
Height
187.5 mm (7.38 in)
Width
187.5 mm (7.38 in)
Length
87.4 mm (3.44 in)
Harmonized System (HS) Code
870739,401699
Country of Origin
India
Weight
0.4 lb
