$55.95
$67.14
FINAL SALE. No returns or exchanges.
This truck part is made by Bendix. We guarantee that all of our parts are from the OEM (original equipment manufacturer), ensuring a proper fit and quality manufacturing.
We honor the warranty provided by the original equipment manufacturer.
DESCRIPTION
The Horn Valve is an essential foot-operated component that enhances safety and communication for commercial truck drivers. This valve is designed to provide reliable actuation of the vehicle's horn, ensuring that you can alert others on the road effectively. With a maximum operating temperature of 200 °F and a minimum of -40 °F, it is built to perform in a wide range of environmental conditions, making it ideal for the rigors of trucking. The valve features a robust construction with multiple ports for easy integration into your vehicle's existing air system. Its compact dimensions allow for efficient use of space, while its user-friendly design ensures smooth operation. At Source One Parts Center, we pride ourselves on offering genuine Bendix OEM parts, making it your best choice for reliable components that enhance your truck's performance and safety.
SPECIFICATIONS
Minimum Operating Temperature
-40 °F (-40 °C)
VMRS
054-001-053: Valve - Air Horn, Single
Supply Port
1/4-18 NPT
Delivery Port
1/8-27 NPT
Maximum Operating Temperature
200 °F (93 °C)
Height
47.8 mm (1.88 in)
Width
50.8 mm (2.0 in)
Harmonized System (HS) Code
848120
Length
91.2 mm (3.59 in)
Button Text
Actuation
Button
Mounting Location
Floor Mounted
Product Type
Foot Operated
Country of Origin
United States
Mounting
Ø .266 IN (2x)
Weight
0.57 lb
