284989N
Synchro Valve
Bendix
UNAVAILABLE
FINAL SALE. No returns or exchanges.
This truck part is made by Bendix. We guarantee that all of our parts are from the OEM (original equipment manufacturer), ensuring a proper fit and quality manufacturing.
We honor the warranty provided by the original equipment manufacturer.
DESCRIPTION
The Synchro Valve from Bendix is a critical component designed to enhance the performance of your vehicle's air or hydraulic systems. This valve ensures seamless operation, helping to maintain optimal pressure levels for effective braking and control. Constructed with high-quality materials, it is engineered to withstand the rigors of heavy-duty use, while its compact design allows for easy installation in various applications. With a maximum operating temperature of 200 °F and a minimum of -40 °F, this valve is built to deliver reliable performance in extreme conditions. For the best in quality and reliability, Source One Parts Center is your premier destination for genuine Bendix OEM parts, ensuring your vehicle operates safely and efficiently.
SPECIFICATIONS
Minimum Operating Temperature
-40 °F (-40 °C)
VMRS
013-010-011: Synchronizing Valve - Air Or Hydraulic
Control Port
1/4-18 NPT
Delivery Port
1/4-18 NPT
Supply Port
1/4-18 NPT
Exhaust Port
1/8-27 NPT (w/ Breather)
Maximum Operating Temperature
200 °F (93 °C)
Exhaust Opening Pressure (Common CON / SUP)
28 PSI
Width
35.1 mm (1.38 in)
Inlet Opening Pressure (Common CON / SUP)
42 PSI
Inlet Opening Pressure Ascending (Constant SUP / Variable CON)
53 PSI
Length
56.9 mm (2.24 in)
Height
73.4 mm (2.89 in)
Harmonized System (HS) Code
848120
Country of Origin
Mexico
Mounting
Ø .28 IN (2x)
Weight
0.55 lb
