285696N
Screw Type Shutoff Cock
Bendix
UNAVAILABLE
FINAL SALE. No returns or exchanges.
This truck part is made by Bendix. We guarantee that all of our parts are from the OEM (original equipment manufacturer), ensuring a proper fit and quality manufacturing.
We honor the warranty provided by the original equipment manufacturer.
DESCRIPTION
The Bendix Screw Type Shutoff Cock is a robust and reliable valve designed for use in air systems of commercial vehicles. This essential component allows for quick and easy shutoff of air supply, making it an important tool for maintenance and emergency situations. With a tee handle design for easy operation, this shutoff cock is constructed to endure the demanding environments of the trucking industry. Weighing only 1.21 lbs, it is compact yet durable, ensuring seamless integration into your air system. Regular checks and maintenance of the shutoff cock can prevent air leaks and ensure efficient operation of your vehicle’s braking system. For high-quality OEM parts, Source One Parts Center is your best choice, providing genuine Bendix components that deliver reliability and performance.
SPECIFICATIONS
Minimum Operating Temperature
-40 °F (-40 °C)
VMRS
013-010-133: Cock - Air Shut-Off
Inlet Port
1/2-14 NPT (Female)
Outlet Port
1/2-14 NPT (Male) / 1/4-18 NPT (Female)
Length
118.4 mm (4.66 in)
Width
124.0 mm (4.88 in)
Maximum Operating Temperature
200 °F (93 °C)
Height
53.8 mm (2.12 in)
Harmonized System (HS) Code
848120
Thread Sealant
No Sealant
Key (In-line) Position
Open
Handle Type
Tee Handle
Country of Origin
United States
Cautionary Note(s)
Use vented delivery on towing trailers (prevent false charging)
Weight
1.21 lb
