DESCRIPTION
The Bendix Drain Valve is a sophisticated component engineered to enhance the performance and longevity of your truck's air brake system. This automatic drain valve efficiently removes moisture and contaminants from the air system, preventing corrosion and ensuring optimal brake functionality. Designed with a heater for cold weather operation, it is capable of maintaining performance even in extreme conditions. With a net weight of just 0.6 kg, this valve is compact yet robust, making it easy to install while ensuring reliability in demanding environments. The valve’s top mount design allows for simple integration into existing systems, making it a preferred choice among professionals. For authentic Bendix OEM parts, trust Source One Parts Center, where we prioritize quality and customer satisfaction in every purchase.
SPECIFICATIONS
Connector Type
#14 GA Hypalon Insulated (No Connector)
Minimum Operating Temperature
-40 °F (-40 °C)
VMRS
013-010-193: Drain Valve - Automatic
Maximum Operating Temperature
100 °F (38 °C)
Harness Length
11.00 IN
Heater Rating
24V
Supply Port (Side)
3/8-18 NPT (Plugged)
Supply Port (Top)
3/8-18 NPT x 1/2-14 NPT (Adapter)
Heater ON Setting (Cut-in)
45° ± 10° F
Height
79.0 mm (3.11 in)
Harmonized System (HS) Code
848140,848180
Heater OFF Setting (Cut-out)
85° ± 10° F
Width
89.7 mm (3.53 in)
Heater Orientation (CW from SUP Port)
90°
Length
93.3 mm (3.68 in)
Country of Origin
Mexico
Thread Sealant
No Sealant
Mounting
Top Mount
Cautionary Note(s)
When mounted, the exhaust must point down toward the road
Heater
Yes
Weight
1.23 lb
