$339.95
$407.94
This truck part is made by Bendix. We guarantee that all of our parts are from the OEM (original equipment manufacturer), ensuring a proper fit and quality manufacturing.
We honor the warranty provided by the original equipment manufacturer.
DESCRIPTION
The Bendix drain valve is a vital component in your air brake system, designed to enhance the efficiency and safety of your vehicle. This valve features a robust construction that allows for reliable operation in demanding conditions, effectively removing moisture from the air brake system to prevent corrosion and ensure optimal performance. With a maximum operating temperature of 200°F and a weight of 0.7 kg, it is engineered for durability and ease of installation. The drain valve operates automatically, providing peace of mind that your brake system remains free from contaminants that could compromise safety. For top-quality Bendix OEM parts, look no further than Source One Parts Center, your best source for reliable components.
SPECIFICATIONS
Minimum Operating Temperature
-40 °F (-40 °C)
VMRS
013-010-193: Drain Valve - Automatic
Maximum Operating Temperature
100 °F (38 °C)
Harness Length
13.50 IN
Heater Rating
24V
Supply Port (Side)
3/8-18 NPT
Supply Port (Top)
3/8-18 NPT x M22 X 1.5 (Adapter)
Heater ON Setting (Cut-in)
45° ± 10° F
Height
71.9 mm (2.83 in)
Harmonized System (HS) Code
848140,848180
Heater OFF Setting (Cut-out)
85° ± 10° F
Width
89.7 mm (3.53 in)
Heater Orientation (CW from SUP Port)
90°
Length
93.3 mm (3.68 in)
Connector Type
Metri-Pack 280 Series 2-Way Sealed Connector (Male)
Country of Origin
Mexico
Thread Sealant
No Sealant
Mounting
Side or Top Mount
Cautionary Note(s)
When mounted, the exhaust must point down toward the road
Heater
Yes
Weight
1.44 lb
