$259.95
$311.94
FINAL SALE. No returns or exchanges.
This truck part is made by Bendix. We guarantee that all of our parts are from the OEM (original equipment manufacturer), ensuring a proper fit and quality manufacturing.
We honor the warranty provided by the original equipment manufacturer.
DESCRIPTION
The Foot Brake Valve from Bendix is a vital component in the braking system, designed for seamless integration and reliable performance in commercial vehicles. This valve features a robust construction that can withstand extreme temperatures, ensuring consistent functionality under varying conditions. Engineered for precise control, it allows for efficient braking operation, enhancing safety for drivers and cargo alike. The valve’s design includes multiple ports, accommodating various configurations for easy installation. For those seeking genuine Bendix OEM parts, Source One Parts Center is the premier destination, offering a comprehensive selection of high-quality components tailored for commercial vehicles.
SPECIFICATIONS
Minimum Operating Temperature
-40 °F (-40 °C)
Mounting Stud Length
0.97 IN
VMRS
013-010-051: Application Valve - Dual
Delivery (21) Port 1
1/2 PTC
Delivery (22) Port 1
1/2 PTC
Delivery (22) Port 2
1/2 PTC
Exhaust Port
1/2-14 NPT
Length
129.5 mm (5.1 in)
Height
151.9 mm (5.98 in)
Maximum Operating Temperature
200 °F (93 °C)
Differential Pressure
3.0 PSI
Delivery (21) Port 2
3/8 PTC
Supply (11) Port 1
3/8 PTC
Supply (12) Port 1
3/8 PTC
Auxiliary Supply Port
3/8-18 NPT
Mounting (Valve Body)
5/16-24 UNF-3A Stud (3x)
Supply (11) Port 2
5/8 PTC
Supply (12) Port 2
5/8 PTC
Harmonized System (HS) Code
848120
Width
91.4 mm (3.6 in)
Regulatory Compliance
FMVSS 121
Country of Origin
Mexico
BVA-85 Included
No
Mounting Nuts / Washers Included
No
Mounting Plate Included
No
Pedal Included
No
Retarder Included
No
Rubber Boot Included
No
Waterproof
No
Port Configuration
Parallel
Graduation Spring Style
Rubber Spring
Weight
3.3 lb
