229509N
Press. Proportioning Valve
Bendix

UNAVAILABLE

Bendix

Non Returnable

FINAL SALE. No returns or exchanges.

This truck part is made by Bendix. We guarantee that all of our parts are from the OEM (original equipment manufacturer), ensuring a proper fit and quality manufacturing.


DESCRIPTION
The Bendix Pressure Proportioning Valve, known for its critical role in modern braking systems, offers exceptional performance and reliability. This valve is engineered to manage the distribution of air pressure to the braking system, ensuring that your vehicle maintains optimal stopping power regardless of the load it carries. With a net weight of 0.5 kg and a compact design, it is easy to install and integrates seamlessly into existing systems. The valve's advanced technology allows for precise control, significantly improving vehicle handling and safety during braking maneuvers. It is built to withstand a broad temperature range, ensuring functionality in diverse operating conditions. This reliability means fewer breakdowns and lower maintenance costs over time. For those who value quality in their vehicle's performance, Source One Parts Center provides the best selection of genuine Bendix OEM parts, ensuring your fleet remains operational and efficient.

SPECIFICATIONS

Minimum Operating Temperature
-40 °F (-40 °C)
VMRS
013-010-010: Limiter Valve - Air
Control Port
1/4-18 NPT
Delivery Port 1
1/4-18 NPT
Delivery Port 2
1/4-18 NPT
Height
100.6 mm (3.96 in)
Maximum Operating Temperature
200 °F (93 °C)
Supply Port
3/8-18 NPT
Limiting Ratio
50% Limited Delivery
Width
63.5 mm (2.5 in)
Length
77.2 mm (3.04 in)
Harmonized System (HS) Code
848120
Delivery Port Orientation (CW from Mounting)
90° / 270°
Country of Origin
Mexico
Exhaust Port
Open
Application
Standard
Mounting
Ø .34 IN (2x)
Weight
1.01 lb
