$229.95
$275.94
FINAL SALE. No returns or exchanges.
This truck part is made by Bendix. We guarantee that all of our parts are from the OEM (original equipment manufacturer), ensuring a proper fit and quality manufacturing.
We honor the warranty provided by the original equipment manufacturer.
DESCRIPTION
The Pressure Proportioning Valve by Bendix is an essential component for regulating brake pressure in your commercial vehicle's braking system. This valve is designed to ensure that the correct amount of pressure is applied to each brake, enhancing overall brake performance and safety. With its robust construction and reliable functionality, this valve is engineered to withstand the demands of heavy-duty applications. Its adjustable features allow for precise control, enabling optimal braking response under various load conditions. By maintaining the balance of brake pressure across the system, this valve helps prevent uneven wear on brake components, extending their lifespan and enhancing safety on the road. Investing in a quality pressure proportioning valve is vital for ensuring consistent braking performance and safety. Source One Parts Center is your best choice for purchasing genuine Bendix OEM parts, ensuring high-quality and reliable components for your commercial vehicles.
SPECIFICATIONS
Minimum Operating Temperature
-40 °F (-40 °C)
VMRS
013-010-010: Limiter Valve - Air
Control Port
1/4-18 NPT
Height
100.6 mm (3.96 in)
Maximum Operating Temperature
200 °F (93 °C)
Delivery Port 1
3/8-18 NPT
Delivery Port 2
3/8-18 NPT
Supply Port
3/8-18 NPT
Limiting Ratio
50% Limited Delivery
Width
63.5 mm (2.5 in)
Length
77.2 mm (3.04 in)
Harmonized System (HS) Code
848120
Delivery Port Orientation (CW from Mounting)
90° / 270°
Country of Origin
Mexico
Exhaust Port
Open
Application
Standard
Mounting
Ø .34 IN (2x)
Weight
0.99 lb
