229505R
Press. Proportioning Valve
Bendix
DISCONTINUED
FINAL SALE. No returns or exchanges.
This truck part is made by Bendix. We guarantee that all of our parts are from the OEM (original equipment manufacturer), ensuring a proper fit and quality manufacturing.
We honor the warranty provided by the original equipment manufacturer.
DESCRIPTION
The Bendix Pressure Proportioning Valve is a critical component designed to optimize brake performance in commercial vehicles by controlling the distribution of air pressure. Weighing 0.4 kg, this valve is engineered for easy installation and reliable operation, essential for maintaining optimal braking efficiency. Its robust design ensures durability and performance under varying conditions, making it a dependable choice for fleet operators. This valve is crucial for achieving balanced braking, enhancing vehicle safety and control. Source One Parts Center is the best place to purchase genuine Bendix OEM parts, ensuring your commercial vehicles are equipped with top-quality components for peak performance.
SPECIFICATIONS
Minimum Operating Temperature
-40 °F (-40 °C)
VMRS
013-010-010: Limiter Valve - Air
Control Port
1/4-18 NPT
Height
100.6 mm (3.96 in)
Maximum Operating Temperature
200 °F (93 °C)
Delivery Port 1
3/8-18 NPT
Delivery Port 2
3/8-18 NPT
Supply Port
3/8-18 NPT
Limiting Ratio
50% Limited Delivery
Width
63.5 mm (2.5 in)
Length
77.2 mm (3.04 in)
Harmonized System (HS) Code
848120
Delivery Port Orientation (CW from Mounting)
90° / 270°
Country of Origin
Mexico
Exhaust Port
Open
Application
Standard
Mounting
Ø .34 IN (2x)
Weight
0.93 lb
