217593N
Safety Valve
Bendix
IN STOCK
More than 10 are currently available
Ships within 1 business day
$35.95
$43.14
This truck part is made by Bendix. We guarantee that all of our parts are from the OEM (original equipment manufacturer), ensuring a proper fit and quality manufacturing.
We honor the warranty provided by the original equipment manufacturer.
DESCRIPTION
The Bendix Safety Valve is a vital component designed to enhance the safety and reliability of your vehicle's braking system. Engineered with precision, this valve ensures optimal airflow and pressure control in various braking applications, providing peace of mind and enhancing vehicle safety. With a compact design and robust construction, this safety valve is built to withstand the rigors of heavy-duty use, making it ideal for commercial vehicles. Its adjustable closing pressure feature allows for fine-tuning to meet specific operational requirements, ensuring consistent performance. For those seeking genuine Bendix OEM parts, Source One Parts Center is the ultimate destination, delivering high-quality components tailored to your specific needs.
SPECIFICATIONS
Minimum Operating Temperature
-40 °F (-40 °C)
VMRS
013-010-073: Safety Valve
Number of Vents
1
Inlet Port
1/4-18 NPT
Length
19.1 mm (0.75 in)
Width
19.1 mm (0.75 in)
Maximum Operating Temperature
200 °F (93 °C)
Closing Pressure
75% of the Minimum Opening Pressure
Height
82.6 mm (3.25 in)
Harmonized System (HS) Code
848140
Opening Pressure
87.5 ± 2.5 PSI
Country of Origin
Mexico
Thread Sealant
No Sealant
Adjustable
Yes
Vent
Ø .125 IN
Weight
0.22 lb
