$339.95
$407.94
This truck part is made by Bendix. We guarantee that all of our parts are from the OEM (original equipment manufacturer), ensuring a proper fit and quality manufacturing.
We honor the warranty provided by the original equipment manufacturer.
DESCRIPTION
The Control Valve from Bendix is a vital component for trailer brake systems, engineered to ensure reliable and precise operation. Weighing 0.6 kg (1.23 lb), this valve provides quick and efficient control of air flow, enhancing the responsiveness of your trailer brakes. Its durable construction allows it to withstand harsh environments, ensuring longevity and dependable performance. By regulating the air supply to the brakes, this control valve plays a crucial role in maintaining optimal braking force, which is essential for safety in commercial vehicle operations. Its design adheres to stringent performance standards, making it a trusted choice for fleet operators. For sourcing genuine Bendix OEM parts, Source One Parts Center is the best source, providing high-quality components that meet the specific demands of commercial vehicles.
SPECIFICATIONS
Minimum Operating Temperature
-40 °F (-40 °C)
VMRS
013-010-049: Parking Valve - Tractor
Plunger / Button Height
1.12 IN
Control (Pilot / AUX) Port
1/8-27 NPT
Delivery Port 1
1/8-27 NPT
Delivery Port 2
1/8-27 NPT
Supply Port
1/8-27 NPT
Pilot Trip Pressure
18 PSI
Maximum Operating Temperature
200 °F (93 °C)
Automatic Release Pressure
40 PSI
Height
45.7 mm (1.8 in)
Width
50.8 mm (2.0 in)
Mounting
7/8-20 UNEF-2A
Harmonized System (HS) Code
848120
Length
99.1 mm (3.9 in)
Country of Origin
Mexico
Button(s) Included
No
Dial Included
No
Exhaust Port
Vent
Mounting Nut Included
Yes
Rubber Boot Included
Yes
Plunger Diameter
Ø .374 IN
Weight
0.86 lb
