103054
Control Valve
Bendix
UNAVAILABLE
FINAL SALE. No returns or exchanges.
This truck part is made by Bendix. We guarantee that all of our parts are from the OEM (original equipment manufacturer), ensuring a proper fit and quality manufacturing.
We honor the warranty provided by the original equipment manufacturer.
DESCRIPTION
The Control Valve from Bendix is engineered to deliver unparalleled performance in air management systems, making it a critical component for commercial vehicles. This three-position valve allows for precise control of air flow, contributing to enhanced braking efficiency and overall vehicle stability. Its robust design ensures durability and reliability under demanding conditions, such as extreme temperatures and heavy loads. The valve features a flipper actuator that provides smooth operation, while its nylon construction offers resistance to wear and tear, ensuring a long service life. Easy to install and maintain, this control valve is essential for optimizing your vehicle's air braking system, making it a must-have for fleet managers and truck owners alike. Ensure your trucks are equipped with the best in air control technology. For genuine Bendix OEM parts, including this Control Valve, Source One Parts Center stands out as your premier choice, providing a seamless shopping experience and expert support.
SPECIFICATIONS
Mounting
#10-24 UNC-3B (2x)
Minimum Operating Temperature
-40 °F (-40 °C)
VMRS
013-010-014: Hand Control Valve - Air
Delivery Port 1
1/8-27 NPT
Delivery Port 2
1/8-27 NPT
Supply Port 1
1/8-27 NPT
Supply Port 2
1/8-27 NPT
Supply Port 4
1/8-27 NPT
Supply Port 3
1/8-27 NPT (Plugged)
Total Travel
100°
Height
125.0 mm (4.92 in)
Maximum Operating Temperature
200 °F (93 °C)
Product Type
3-Position Valve (Z-Shift)
Length
54.1 mm (2.13 in)
Width
69.1 mm (2.72 in)
Harmonized System (HS) Code
848120
Actuator Finish
Black
Lever Position 1
DEL 1 / DEL 2
Lever Position 3
DEL 1 / EXH 2
Lever Position 2
EXH 1 / DEL 2
Actuator Style
Flipper
Country of Origin
Mexico
Actuator Material
Nylon
Mechanism Type
Positioning
Exhaust Port
Vent
Weight
0.88 lb
