DESCRIPTION
The Control Valve is a vital element in managing your truck's braking system, specifically designed to optimize air pressure control for operational efficiency. With a total handle travel of 90° and a compact design, this valve allows for precise adjustments, ensuring responsive brake functionality under all conditions. Constructed from durable materials, it can withstand high temperatures and is built to last, making it an ideal choice for heavy-duty vehicles. Weighing in at only 0.3 kg, this Control Valve offers ease of installation and maintenance, allowing you to keep your braking system running smoothly without hassle. By regulating air pressure effectively, it enhances overall vehicle safety and performance. For those seeking reliable Bendix parts, Source One Parts Center is the top destination for purchasing genuine OEM components that guarantee quality and durability.
SPECIFICATIONS
Minimum Operating Temperature
-40 °F (-40 °C)
VMRS
013-010-049: Parking Valve - Tractor
Plunger / Button Height
1.59 IN
Delivery Port 1
1/8-27 NPT
Delivery Port 2
1/8-27 NPT
Exhaust Port
1/8-27 NPT
Supply Port
1/8-27 NPT
Length
102.6 mm (4.04 in)
Automatic Release Pressure
20 PSI
Maximum Operating Temperature
200 °F (93 °C)
Height
45.7 mm (1.8 in)
Width
50.8 mm (2.0 in)
Mounting
7/8-20 UNEF-2A
Harmonized System (HS) Code
848120
Button Color
Black (Red Band)
Cautionary Note(s)
Don't install fittings in Exhaust Port for Parking Applications
Country of Origin
Mexico
Dial Included
No
Rubber Boot Included
No
Button Text
Push to Charge | Emergency Brake | Not for Parking | Pull for Emergency
Button Shape
Round
Button(s) Included
Yes
Mounting Nut Included
Yes
Plunger Diameter
Ø .374 IN
Weight
0.66 lb
