K020086
Trailer Control Valve
Bendix
DISCONTINUED
FINAL SALE. No returns or exchanges.
This truck part is made by Bendix. We guarantee that all of our parts are from the OEM (original equipment manufacturer), ensuring a proper fit and quality manufacturing.
We honor the warranty provided by the original equipment manufacturer.
DESCRIPTION
The Trailer Control Valve is an essential component for managing the air brakes on your truck's trailer. Designed for precision and reliability, this valve features a self-return mechanism that allows for easy operation, making it a crucial addition for any commercial vehicle. Its robust construction and ability to operate effectively in extreme temperatures ensure that your braking system remains reliable in all conditions. With multiple ports for versatile installation, this valve is engineered to optimize your braking performance, ensuring safety on the road. Source One Parts Center is the ideal choice for purchasing genuine Bendix OEM parts, providing you with quality products that enhance your vehicle's performance.
SPECIFICATIONS
Minimum Operating Temperature
-40 °F (-40 °C)
Graduating Pressure Range
0 - 40 PSI
VMRS
013-010-014: Hand Control Valve - Air
Exhaust Port
1/4 PTC (Straight / Composite)
Final Delivery Pressure
120 PSI
Maximum Operating Temperature
200 °F (93 °C)
Delivery Port
3/8 PTC (Straight / Gray Cap)
Supply Port
3/8 PTC (Straight)
Total Handle Travel
40°
Harmonized System (HS) Code
848120
Mounting Location
Dash Mount
Cautionary Note(s)
Exhaust Port must vent to atmosphere - do not pressurize
Country of Origin
Mexico
Body Material
Plastic
Handle Material
Plastic
Product Type
Self-Return (with Detent)
Handle Shape
Straight
Mounting
Ø .218 IN (4x)
Weight
0.5 lb
