K031988
Trailer Control Valve
Bendix
DISCONTINUED
FINAL SALE. No returns or exchanges.
This truck part is made by Bendix. We guarantee that all of our parts are from the OEM (original equipment manufacturer), ensuring a proper fit and quality manufacturing.
We honor the warranty provided by the original equipment manufacturer.
DESCRIPTION
The Bendix Trailer Control Valve is an essential device designed to enhance the performance of your truck's braking system. This self-return valve features a robust design that ensures reliable operation and safety during towing operations. Constructed with durability in mind, it offers a maximum operating temperature of 200°F, making it suitable for demanding environments. The valve's angled handle design allows for easy operation, ensuring that drivers can control their trailer brakes efficiently. Weighing just 0.4 kg, it is compact and easy to install, making it an ideal choice for fleet managers looking to enhance their vehicles' braking capabilities. When it comes to sourcing reliable parts, Source One Parts Center is the best place to purchase genuine Bendix OEM parts for your commercial vehicles, ensuring you receive high-quality components every time.
SPECIFICATIONS
Minimum Operating Temperature
-40 °F (-40 °C)
Graduating Pressure Range
0 - 40 PSI
VMRS
013-010-014: Hand Control Valve - Air
Exhaust Port
1/4 PTC (Straight / Composite)
Final Delivery Pressure
135 PSI
Maximum Operating Temperature
200 °F (93 °C)
Delivery Port
3/8 PTC (Straight / Gray Cap)
Supply Port
3/8 PTC (Straight)
Total Handle Travel
55°
Harmonized System (HS) Code
848120
Handle Shape
Angled
Mounting Location
Dash Mount
Cautionary Note(s)
Exhaust Port must vent to atmosphere - do not pressurize
Country of Origin
Mexico
Body Material
Plastic
Product Type
Self-Return (without Detent)
Handle Material
Steel (Black Oxide)
Mounting
Ø .268 IN, .295 IN x .220 IN Slot, .374 IN x .276 IN Slot (2x)
Weight
0.88 lb
