4051634C92
CYLINDER, HYDRAULIC POWER BRAKE
Navistar International®
BACK ORDERED
Please contact us for information on lead time
$649.95
$779.94
This truck part is made by Navistar International®. We guarantee that all of our parts are from the OEM (original equipment manufacturer), ensuring a proper fit and quality manufacturing.
We honor the warranty provided by the original equipment manufacturer.
SPECIFICATIONS
OEM Description
CYLINDER, HYDRAULIC POWER BRAKE,
BILL OF MATERIALS
| Name | Quantity | Part Number |
|---|---|---|
| NUT, SELF LOCKING 3/8-16 UNC-2B | 4 | 2514411C1 |
| SWITCH, FLOW SWITCH | 1 | 2514230C91 |
| METERING PISTON, FLOW SWITCH | 1 | 2514229C1 |
| O-RING, INLET CHECK VALVE | 1 | 2514227C1 |
| SEAT, CHECK VALVE | 1 | 2514226C1 |
| BALL, CHECK VALVE | 1 | 2514225C1 |
| O-RING PREFORMED | 1 | 1696495C1 |
| RELAY, BACKUP PUMP MOTOR | 1 | BX2772777 |
| SCREW, 3/8-16 UNC-2A | 2 | 2514412C1 |
| SEAT TUBE | 1 | BX2228139 |
| NUT, HEXAGON LOCK FLGD 3/8-16 UNC 3/8" UNC | 1 | 1515459C1 |
| BOLT, HYDROMAX MOTOR MOUNTING | 1 | 2507097C1 |
| SWITCH, HYDRAULIC BRAKE LOW PRESSURE | 1 | 1677210C91 |
| SWITCH, FLUID, BRAKE MASTER CYLINDER | 1 | 2514224C1 |
| CAP, W/DIAPHRAGM MASTER CYLINDER. | 1 | 2517548C91 |
| SCREW, SELF TAPPING | 1 | 3558865C1 |
| HOUSING, MOUNTING | 2 | 2514413C1 |
| GASKET BOOSTER TO MASTER CYLINDER | 1 | 2514415C1 |
| RING, FLOW SWITCH | 1 | 2514414C1 |
| HYDROMAX BOOSTER SVC. | 1 | 2514231C91 |
| SPRING, FLOW SWITCH | 1 | 2514228C1 |
| MASTER CYLINDER SVC. | 1 | 2514232C91 |
| MOTOR | 1 | BHN2772876 |
| MOTOR AND PUMP SVC. | 1 | 2514233C91 |
RECOMMENDED PARTS
* This information is provided as is and may be out of date. Please contact us or the manufacturer to verify warranty
coverage.
