3809173C99
BOX CONSOLE TWR CABINET ASSEMBLY R WITH COVER
Navistar International®
BACK ORDERED
Please contact us for information on lead time
$1,349.95
$1,619.94
This truck part is made by Navistar International®. We guarantee that all of our parts are from the OEM (original equipment manufacturer), ensuring a proper fit and quality manufacturing.
We honor the warranty provided by the original equipment manufacturer.
RELATED PARTS
SPECIFICATIONS
OEM Description
BOX CONSOLE TWR CABINET ASSEMBLY R WITH COVER
BILL OF MATERIALS
| Name | Quantity | Part Number |
|---|---|---|
| REINFORCEMENT TOWER CABINET FR | 1 | 3668357C6 |
| WASHER, LOCK HELICAL SPRING 1.121PP M4 | 35 | 933832R1 |
| PANEL | 1 | 3667215C6 |
| PANEL TOWER CABINET SIDE ASSEMBLY REAR W/SNAPS | 1 | 3667216C6 |
| PANEL ASSEMBLY, BOTTOM TOWER CABINET | 1 | 3809161C94 |
| PANEL ASSEMBLY, FRONT TOWER CABINET | 1 | 3809170C5 |
| " ROD, CLOTHES" | 1 | 3665813C1 |
| " PANEL, SHELF"UPPER RIGHT HAND | 1 | 3666823C1 |
| " COVER ASSEMBLY, CABINET"TOWER | 1 | 3665836C1 |
| SCREW M4, PAN HEAD, 16MM | 35 | 3667100C1 |
RECOMMENDED PARTS
* This information is provided as is and may be out of date. Please contact us or the manufacturer to verify warranty
coverage.
