6103634C93
BOX, CONSOLE, DRESSER CABINET ASSEMBLY
Navistar International®
BACK ORDERED
Please contact us for information on lead time
$1,799.95
$2,159.94
This is an oversize product. Additional shipping fees may apply.
This truck part is made by Navistar International®. We guarantee that all of our parts are from the OEM (original equipment manufacturer), ensuring a proper fit and quality manufacturing.
We honor the warranty provided by the original equipment manufacturer.
RELATED PARTS
SPECIFICATIONS
OEM Description
BOX, CONSOLE, DRESSER CABINET ASSEMBLY
Weight
76 lbs
BILL OF MATERIALS
| Name | Quantity | Part Number |
|---|---|---|
| BOX CONSOLE DRESSER CABINET DRAWER ASSEMBLY SMALL | 1 | 3803040C93 |
| SUPPORT, REFRIGERATOR CABINET BACK | 1 | 4071956C1 |
| PANEL, LOWER CABINET MAGAZINE POCKET | 1 | 3802271C3 |
| REINFORCEMENT REFRIGERANT CABINET STEEL TOP | 1 | 3802286C2 |
| TAPE, TRIM LOWER CABINET FOAM PAD | 2 | 3802315C1 |
| MAT, CARPET CONSOLE BOX REFRIGERATOR TOP | 1 | 3802739C2 |
| REINFORCEMENT DRESSER CABINET FR ASSEMBLY | 1 | 3803044C5 |
| SCREW, SYSTEM FLAT HEAD 20MM | 18 | 3803120C2 |
| RIVET STEEL 3/16" | 12 | 3803071C1 |
| SPACER, BUMPER RUBBER | 3 | 3802839C1 |
| SUPPORT, BRACKET DRESSER | 1 | 3805609C1 |
| BOX CONSOLE DRESSER CABINET DRAWER ASSEMBLY LARGE | 2 | 3803041C93 |
| REINFORCEMENT STRIKER | 3 | 3802692C2 |
| SCREW PAN HEAD TORX M 4 X 14MM | 10 | 3807410C1 |
| GRAPHICS, PRODUCT WORK SURFACE | 1 | 3815537C1 |
| SPACER RUBBER BUMPER-CABINETS | 6 | 3727899C1 |
| BOX CONSOLE REFRIGERATOR CABINET WORK SURFACE ASSEMBLY | 1 | 3803042C95 |
| RIVET, BLIND 3/16" | 8 | 3808364C1 |
| STRAP, ATTACHING 74" BLACK | 1 | 3619710C1 |
| SCREW PAN HEAD TORX BLACK M 5 X 16MM | 13 | 3805951C1 |
| PANEL, REFRIGERATOR CABINET TOP | 1 | 3802242C3 |
| PANEL, REFRIGERATOR CABINET SIDE FRONT | 1 | 3802244C5 |
| PANEL, REFRIGERATOR CABINET SIDE REAR | 1 | 3802245C5 |
RECOMMENDED PARTS
* This information is provided as is and may be out of date. Please contact us or the manufacturer to verify warranty
coverage.
