3506626C91
PANEL, LEFT SIDE BODY
Navistar International®
BACK ORDERED
Please contact us for information on lead time
$1,049.95
$1,259.94
This is an oversize product. Additional shipping fees may apply.
This truck part is made by Navistar International®. We guarantee that all of our parts are from the OEM (original equipment manufacturer), ensuring a proper fit and quality manufacturing.
We honor the warranty provided by the original equipment manufacturer.
SPECIFICATIONS
OEM Description
PANEL, LEFT SIDE BODY
Weight
75.16 lbs
BILL OF MATERIALS
| Name | Quantity | Part Number |
|---|---|---|
| FR DOOR OPENING LEFT | 1 | 1669623C93 |
| NUT, RIVET 1/4" UNC | 1 | 795633C1 |
| RIVET, SPECIAL SOLID 3/16" X 7/16" | 20 | 9401792 |
| EXTENSION, CAB PANEL OUTER LEFT REAR | 1 | 403193C2 |
| ANGLE PANEL REAR CORNER | 1 | 403124C3 |
| EXTENSION, CAB PANEL OUTER LEFT REAR | 1 | 403193C1 |
| PANEL, LEFT INNER LOCK PILLAR | 1 | 403293C6 |
| PANEL, LEFT OUTER REAR CORNER ALUMINUM | 1 | 1658359C2 |
| REINFORCEMENT, DOOR OPENING LEFT SIDE HDER | 1 | 403130C2 |
| EXTENSION, REAR HDER CAB PANEL LOWER LEFT REAR ALUMINUM | 1 | 403178C2 |
| PANEL, INNER LEFT SIDE HDER | 1 | 598993C3 |
| PANEL, INNER LEFT SIDE HEADER | 1 | 598993C2 |
| RIVET, BRAZIER HD 3/16" 3/8" GRIP | 14 | 351554C1 |
| PANEL, LEFT WINDSHIELD ALUMINUM | 1 | 403170C3 |
| PANEL, INNER LEFT COWL | 1 | 2026017C2 |
| RIVET, BLIND | 57 | 2040952C1 |
| PANEL, LEFT OUTER COWL | 1 | 2004960C4 |
| PANEL SILL- SIDE OUTER-LH | 1 | 2023195C2 |
| PANEL SILL- SIDE OUTER-LH | 1 | 598517C1 |
RECOMMENDED PARTS
* This information is provided as is and may be out of date. Please contact us or the manufacturer to verify warranty
coverage.
