3525100C94
CLUSTER ,INSTRUMENT AIR BRAKE-ENGLISH SPEEDOMETER /TACHOMETER W/ELECTRICAL ENGINE
Navistar International®
BACK ORDERED
Please contact us for information on lead time
FINAL SALE. No returns or exchanges.
This truck part is made by Navistar International®. We guarantee that all of our parts are from the OEM (original equipment manufacturer), ensuring a proper fit and quality manufacturing.
We honor the warranty provided by the original equipment manufacturer.
RELATED PARTS
SPECIFICATIONS
VMRS
045-018-009
OEM Description
CLUSTER ,INSTRUMENT AIR BRAKE-ENGLISH SPEEDOMETER /TACHOMETER W/ELECTRICAL ENGINE
Package Dimensions
10.0 x 5.0 x 20.0 in
Weight
5.01 lbs
BILL OF MATERIALS
| Name | Quantity | Part Number |
|---|---|---|
| HOUSING, INSTRUMENT CLUSTER W/CIRCUIT BOARDS | 1 | 3595124C1 |
| BOARD, PRINTED CIRCUIT LEFT INSTRUMENT CLUSTER | 1 | 2587517C1 |
| BOARD, PRINTED CIRCUIT RIGHT INSTRUMENT CLUSTER | 1 | 2587519C1 |
| BOARD, PRINTED CIRCUIT CENTER INSTRUMENT CLUSTER | 1 | 2587521C3 |
| BOARD, PRINTED CIRCUIT CENTER INSTRUMENT CLUSTER | 1 | 2587521C1 |
| GAUGE BATTERY, GENERATOR VOLT METER | 1 | 3514875C1 |
| GAUGE DUAL AIR PRESSURE ENGLISH | 1 | 1690255C1 |
| BEZEL, INSTRUMENT CLUSTER | 1 | 1690296C1 |
| LENS, INSTRUMENT CLUSTER LIGHT RIGHT TURN | 1 | 1690282C1 |
| LENS, INSTRUMENT CLUSTER LEFT TURN | 1 | 1690281C1 |
| METER, ODOMETER SPEEDOMETER | 1 | 1685151C1 |
| PRODUCT GRAPHICS ODOMETER (ENGLISH) | 1 | 1690288C1 |
| LENS, INSTRUMENT CLUSTER LIGHT 4 PACKAGE TRAILER ANTILOCK BRAKE SYSTEM (ABS) (ANTILOCK BRAKE SYSTEM (ABS)) RIGHT | 1 | 3560957C1 |
| LENS, INSTRUMENT CLUSTER LIGHT 4 PACKAGE LEFT | 1 | 1690284C1 |
| COVER, GAUGE HOLE SMALL | 3 | 1690285C1 |
| COVER, GAUGE HOLE MEDIUM | 1 | 1690286C1 |
| TACHOMETER, ELECTRONIC | 1 | 1690276C1 |
| SPEEDOMETER, ELECTRONIC ENGLISH | 1 | 1690274C1 |
| LENS, ENGLISH INSTRUMENT CLUSTER LIGHT ELECTRONIC ENGINES LEFT | 1 | 3524856C1 |
| LENS, ENGLISH INSTRUMENT CLUSTER LIGHT RIGHT | 1 | 1690277C1 |
| PRODUCT GRAPHICS HOURMETER | 1 | 1690295C1 |
| GAUGE TRANSMISSION OIL TEMPERATURE RECEIVER ENGLISH | 1 | 1690264C1 |
| GAUGE ELECTRONIC OIL PRESSURE RECEIVER ENGLISH | 1 | 3514870C1 |
| GAUGE WATER TEMPERATURE RECEIVER ENGLISH | 1 | 3524858C1 |
| GAUGE FUEL RECEIVER | 1 | 1690273C1 |
CROSS REFERENCES
- POLLAK 32180-344
- POLLAK 32180-344
- STONERI 32180-344
- STONERI 32180-344
- STONERI 32180344
- STONERI 32180344
RECOMMENDED PARTS
* This information is provided as is and may be out of date. Please contact us or the manufacturer to verify warranty
coverage.
