3683724C92
SUPPORT, HANGER LIGHTED MUD FLAP
Navistar International®
BACK ORDERED
Please contact us for information on lead time
$1,349.95
$1,619.94
This truck part is made by Navistar International®. We guarantee that all of our parts are from the OEM (original equipment manufacturer), ensuring a proper fit and quality manufacturing.
We honor the warranty provided by the original equipment manufacturer.
RELATED PARTS
SPECIFICATIONS
VMRS
014-001-000
OEM Description
SUPPORT, HANGER LIGHTED MUD FLAP
Weight
25.05 lbs
BILL OF MATERIALS
| Name | Quantity | Part Number |
|---|---|---|
| LIGHT, LED RED W/AMP CONNECTOR W/AMP CONNECTOR | 3 | 2599651C1 |
| INSERT B | 6 | PL00812524 |
| WASHER, STAINLESS STEEL | 4 | 2602173C1 |
| STRIP, CONSPICUITY RED /WHITE | 1 | 2599653C1 |
| BAR, LIGHT REAR FLAP HANGER RIGHT | 1 | 2599659C1 |
| BAR, LIGHT REAR STAINLESS STEEL RIGHT | 1 | 2599660C1 |
| BAR, REAR LITE ,UNIV BASE ASSEMBLY | 1 | PL90581004 |
| PLATE, NUT, LIGHT BAR REAR | 2 | 2599656C1 |
| PLATE, BACKING REAR LIGHT BAR | 1 | 2602172C1 |
| HARNESS, LIGHT BAR REAR | 1 | 2599657C1 |
| BRACKET, M4 BEZEL | 3 | PL00212117 |
| LIGHT, LED RED W/CLEAR LENS W/CLEAR LENS | 3 | 2599652C1 |
| BEZEL M5 | 3 | PL00212717 |
| 8X5/8 | 8 | PL00812328 |
| 1/4 X 5/SST WASHER | 8 | PL00812323 |
| BOLT, CARRIAGE STAINLESS STEEL | 4 | 2602174C1 |
| RIVET 3/16" SST | 6 | PL00812376 |
| NUT, HEXAGON ,1/4-20 N SST | 4 | PL00812402 |
| SCREW, HEXAGON ,3/8-16 X 2 SST | 4 | PL00812440 |
| WASHER, FLAT 3/8 X 7/8 SST | 4 | PL00812441 |
| SCREW, HEXAGON HEAD ,1/4-20 X 1 SST | 4 | PL00812455 |
CROSS REFERENCES
- PANELIT 42584401
- PANELIT 42584401
RECOMMENDED PARTS
* This information is provided as is and may be out of date. Please contact us or the manufacturer to verify warranty
coverage.
