3722871C3
SUPPORT PANEL ASSEMBLY RIGHT HAND, EXTND SKIRT
Navistar International®
BACK ORDERED
Please contact us for information on lead time
$244.95
$293.94
This truck part is made by Navistar International®. We guarantee that all of our parts are from the OEM (original equipment manufacturer), ensuring a proper fit and quality manufacturing.
We honor the warranty provided by the original equipment manufacturer.
SPECIFICATIONS
OEM Description
SUPPORT PANEL ASSEMBLY RIGHT HAND, EXTND SKIRT
Weight
12.001 lbs
BILL OF MATERIALS
| Name | Quantity | Part Number |
|---|---|---|
| SUPPORT PANEL UPPER ASSEMBLY LH, EXTND SKIRT | 1 | 3722872C3 |
| SUPPORT PANEL LOWER LH, EXTND SKIRT | 1 | 3722868C3 |
| TUBE PANEL VERTICAL SUPPORT LH /RIGHT HAND, EXTND SKRT | 1 | 3722875C1 |
| ROD SUPPORT PANEL VERTICAL, EXTND SKIRT | 2 | 3722876C1 |
| REINFORCEMENT LOWER PANEL, EXTND SKIRT | 4 | 3887055C1 |
RECOMMENDED PARTS
* This information is provided as is and may be out of date. Please contact us or the manufacturer to verify warranty
coverage.
