3807955C98
SUPPORT CHASSIS SKIRT ASSEMBLY-*
Navistar International®
AVAILABLE
More than 10 are currently available
Ships within 6-8 business days
$919.95
$1,103.94
This truck part is made by Navistar International®. We guarantee that all of our parts are from the OEM (original equipment manufacturer), ensuring a proper fit and quality manufacturing.
We honor the warranty provided by the original equipment manufacturer.
RELATED PARTS
SPECIFICATIONS
VMRS
014-002-030
OEM Description
SUPPORT CHASSIS SKIRT ASSEMBLY-*
Package Dimensions
41.0 x 35.5 x 5.75 in
Weight
21.04 lbs
BILL OF MATERIALS
| Name | Quantity | Part Number |
|---|---|---|
| SUPPORT CHASSIS SKIRT-* | 1 | 3807959C1 |
| PIN SPLIT (COTTER)- EXTENDED PRONG | 2 | 220257 |
| SUPPORT CHASSIS SKIRT- | 1 | 3618062C97 |
| SUPPORT CHASSIS SKIRT- | 1 | 3618063C98 |
| SLEEVE COMP OR FLEX TUBE HANDLE-* | 1 | L2643504 |
| SLEEVE COMP OR FLEX TUBE HANDLE-* | 1 | 3809419C1 |
| BUSHING, CLUTCH PEDAL | 2 | 277523R1 |
| PIN, COTTER STAINLESS STEEL | 1 | 40335R1 |
| SUPPORT CHASSIS SKIRT-* | 1 | 3807957C2 |
| SUPPORT CHASSIS SKIRT-* | 2 | 3807962C1 |
| SUPPORT, CHASSIS SKIRT | 2 | 3618040C1 |
CROSS REFERENCES
- JB HUNT 25463
- JB HUNT 25463
RECOMMENDED PARTS
* This information is provided as is and may be out of date. Please contact us or the manufacturer to verify warranty
coverage.
