3551834C96
HOOD AS PURCHASED- WITH HEAD LIGHT
Navistar International®
BACK ORDERED
Please contact us for information on lead time
$2,799.95
$3,359.94
This is an oversize product. Additional shipping fees may apply.
This truck part is made by Navistar International®. We guarantee that all of our parts are from the OEM (original equipment manufacturer), ensuring a proper fit and quality manufacturing.
We honor the warranty provided by the original equipment manufacturer.
SPECIFICATIONS
OEM Description
HOOD AS PURCHASED-W/HEAD LIGHT
Weight
349.8 lbs
BILL OF MATERIALS
| Name | Quantity | Part Number |
|---|---|---|
| PANEL W/HEAD LIGHT | 1 | 3535327C2 |
| BRACE ASSEMBLY, HINGE HOOD | 1 | 3513391C2 |
| BOLT 3/8" X 1" | 8 | 24840R1 |
| PRODUCT GRAPHIC ,ORNMT HOOD SERIAL NUMBER | 1 | 2006830C1 |
| RIVET, BLIND POP | 2 | 487159C1 |
| PANEL, GRILLE SURROUND | 1 | 3535337C1 |
| RETAINER, ENGINE COVER INSULATION BLACK PLASTIC PUSH- INCH | 5 | 489348C1 |
| GUSSET, SPLASH PANEL FRONT LEFT | 1 | 3542585C1 |
| GUSSET, SPLASH PANEL FRONT RIGHT | 1 | 3542586C1 |
| INSULATOR, HOOD MOUNTING ROUND ISOLATOR | 2 | 3839702C1 |
| WASHER, LOCK ZINC PLATED 3/8" | 8 | 120382 |
| REINFORCEMENT LH REAR ASSEMBLY | 1 | 3551831C1 |
| WASHER 3/8" | 8 | 120388 |
| REINFORCEMENT RIGHT HAND REAR ASSEMBLY | 1 | 3551833C1 |
| REINFORCEMENT LH FRONT ASSEMBLY | 1 | 3541503C1 |
| REINFORCEMENT RIGHT HAND FRONT ASSEMBLY | 1 | 3541504C1 |
| REINFORCEMENT LH SIDE ASSEMBLY | 1 | 3541501C1 |
| REINFORCEMENT RIGHT HAND SIDE ASSEMBLY | 1 | 3541502C1 |
| HOUSING, HDLAMP | 2 | 591333C1 |
| RIVET, BLIND CHERRY | 20 | 791280C1 |
RECOMMENDED PARTS
* This information is provided as is and may be out of date. Please contact us or the manufacturer to verify warranty
coverage.
