3707881C93
HOOD ASSEMBLY ,HDD113,W/HOLES ,SFA
Navistar International®
BACK ORDERED
Please contact us for information on lead time
$3,199.95
$3,839.94
This truck part is made by Navistar International®. We guarantee that all of our parts are from the OEM (original equipment manufacturer), ensuring a proper fit and quality manufacturing.
We honor the warranty provided by the original equipment manufacturer.
SPECIFICATIONS
OEM Description
HOOD ASSEMBLY ,HDD113,W/HOLES ,SFA
BILL OF MATERIALS
| Name | Quantity | Part Number |
|---|---|---|
| PANEL HOOD TOP | 1 | 6089707C2 |
| SUPPORT HOOD, ASSIST MNTG ASSEMBLY, RIGHT HAND | 1 | 3867992C1 |
| INSULATOR HOOD MOUNTING D-STYLE ISOLATOR | 2 | 3839700C1 |
| NUT, SPEED "U" M8 X 1.25 MM | 3 | 3551059C1 |
| RETAINER BRACKET, MARKER- TURN WIRING | 2 | 3853847C1 |
| BOLT, TORX PLUS M6 X 1-20 | 2 | 3535316C1 |
| NUT W/FREE SPIN WASHER M6 | 2 | 3608911C1 |
| BRACE DAMPER TO HOOD | 1 | 3850946C2 |
| PANEL HOOD SIDE ,W/HOLES ,SFA, LH | 1 | 3707900C2 |
| PANEL HOOD SIDE ,W/HOLES ,SFA, RIGHT HAND | 1 | 3707901C2 |
| BAR HOOD SUPPORT PIVOT, ASSEMBLY | 1 | 6089710C2 |
| BOLT M10 X 40MM | 8 | 30866R2 |
| REINFORCEMENT HOOD, FRONT | 1 | 6089711C3 |
| REINFORCEMENT HOOD REAR LH ASSEMBLY | 1 | 6089712C92 |
| REINFORCEMENT HOOD REAR RIGHT HAND ASSEMBLY | 1 | 6089713C93 |
| SUPPORT HOOD, ASSIST MOUNTING ASSEMBLY LH | 1 | 3867991C1 |
RECOMMENDED PARTS
* This information is provided as is and may be out of date. Please contact us or the manufacturer to verify warranty
coverage.
