3566083C1
STRAP, FUEL TANK MOUNTING
Navistar International®
BACK ORDERED
Please contact us for information on lead time
$389.95
$467.94
This truck part is made by Navistar International®. We guarantee that all of our parts are from the OEM (original equipment manufacturer), ensuring a proper fit and quality manufacturing.
We honor the warranty provided by the original equipment manufacturer.
SPECIFICATIONS
OEM Description
STRAP, FUEL TANK MOUNTING
Package Dimensions
52.0 x 9.0 x 2.0 in
Weight
9.02 lbs
BILL OF MATERIALS
| Name | Quantity | Part Number |
|---|---|---|
| STRAP, FUEL TANK MOUNTING ASSEMBLY 24" DIAMETER TANK STEEL W/STEPS | 1 | 3528806C2 |
| RIVET, 3/16 X 1/2 PLN F/HD SOL | 16 | 104235 |
| BRACKET, FUEL TANK STEP | 2 | 3566117C1 |
| BRACKET, FUEL TANK STEP MOUNTING | 1 | 556689C1 |
| SUPPORT FUEL TANK STEP RIGHT | 1 | 556690C1 |
| SUPPORT FUEL TANK STEP LEFT | 1 | 556699C2 |
| SUPPORT FUEL TANK STEP RIGHT | 1 | 556700C2 |
RECOMMENDED PARTS
* This information is provided as is and may be out of date. Please contact us or the manufacturer to verify warranty
coverage.
