3683887C4
FR, SEAT ASSEMBLY BACKREST WELDMENT DUAL RISER LEFT HAND 30"
IC Bus
BACK ORDERED
Please contact us for information on lead time
$269.95
$323.94
This truck part is made by IC Bus. We guarantee that all of our parts are from the OEM (original equipment manufacturer), ensuring a proper fit and quality manufacturing.
We honor the warranty provided by the original equipment manufacturer.
SPECIFICATIONS
OEM Description
FR, SEAT ASSEMBLY BACKREST WELDMENT DUAL RISER LH 30"
Package Dimensions
41.0 x 35.0 x 6.0 in
Weight
21.043 lb
BILL OF MATERIALS
| Name | Quantity | Part Number |
|---|---|---|
| TUBE SEATBACK FR SUPPORT 30" | 1 | 3682015C1 |
| PANEL SEATBACK FR DUAL RISER 30" | 1 | 3822456C3 |
| REINFORCEMENT SEAT FR EXTENSION | 2 | 3821589C1 |
| SUPPORT SEAT FR SIDE DUAL RISER | 1 | 3821592C2 |
