440361003
FR ASSEMBLY SEAT 4- LEG
IC Bus
BACK ORDERED
Please contact us for information on lead time
$1,399.95
$1,679.94
This is an oversize product. Additional shipping fees may apply.
This truck part is made by IC Bus. We guarantee that all of our parts are from the OEM (original equipment manufacturer), ensuring a proper fit and quality manufacturing.
We honor the warranty provided by the original equipment manufacturer.
RELATED PARTS
SPECIFICATIONS
OEM Description
FRAME ASSY SEAT COMPLETE 4-LE
Weight
45.1 lbs
BILL OF MATERIALS
| Name | Quantity | Part Number |
|---|---|---|
| FR, UPPER SEAT 4- LEG | 1 | 440365003 |
| TUBE SEAT PASS SUPPORT 1997 | 1 | 440217001 |
| LEG, SEAT ASSEMBLY ANCHOR DOT 1997 | 2 | 440363001 |
| BRACE RIGHT HAND ANCHOR AISLE SIDE | 1 | 440374002 |
| BRACE LH ANCHOR WALL SIDE | 1 | 440375001 |
| BRACE LEG LH ANCHOR | 1 | 440373001 |
| BRACE LEG RIGHT HAND ANCHOR | 1 | 440373002 |
| PLATE DOT 1997 ST 4-LE | 1 | 440369008 |
| STRIP, TACK SEAT DOT 1997 COMMUNICATION | 1 | 439060007 |
| SCREW, PAN HEAD COUNTERSUNK TYPE AB PLATED #8 X 1" | 7 | 91306000 |
| TUBE STEEL SQUARE 1" X 1" X | 1 | 413355039 |
| STRIP, TACK SEAT DOT 1997 39" | 1 | 439060009 |
| PLATE DOT 1997 ST 4-LE | 1 | 440369013 |
