443804001
FR ASSEMBLY 39" AUTOMATIC FLIP SEAT
IC Bus
BACK ORDERED
Please contact us for information on lead time
$589.95
$707.94
This is an oversize product. Additional shipping fees may apply.
This truck part is made by IC Bus. We guarantee that all of our parts are from the OEM (original equipment manufacturer), ensuring a proper fit and quality manufacturing.
We honor the warranty provided by the original equipment manufacturer.
RELATED PARTS
SPECIFICATIONS
OEM Description
FR ASSEMBLY 39" AUTOMATIC FLIP SEAT
Weight
63.13 lbs
BILL OF MATERIALS
| Name | Quantity | Part Number |
|---|---|---|
| PLATE ASSEMBLY SB 39" AUTOFLIP 1999 | 2 | 443833001 |
| PLATE, SEAT BELT ANCHOR 39" AUTOFLIP | 2 | 452940001 |
| TUBE SEAT FR OFFSET /COMBO 8.88 | 2 | 429688001 |
| LEG, SEAT AUTOMATIC FLIP W/ANCHOR | 2 | 433172001 |
| FR ASSEMBLY 39" AUTOFLIP SEAT BOTTOM W/HINGE | 1 | 452941001 |
| FR, 39" SEAT BOTTOM | 1 | 443819001 |
| STEEL BAR CR .94" DIAMETER 24.50" | 1 | 416028039 |
| SUPPORT FR AUTOFLIP SEAT W/ANCHOR RIGHT HAND | 1 | 434548002 |
| PLATE, SEAT BELT ANCHOR | 1 | 443834001 |
| SUPPORT FR AUTOFLIP SEAT W/ANCHOR LH | 1 | 434548001 |
| TUBE ASSEMBLY, OFFSET FLIPSEAT STANDARD | 1 | 2202694C1 |
| TUBE CRASH-BARRIER ASSEMBLY FLIPSEAT OFFSET STANDARD | 1 | 443433005 |
| FR ASSEMBLY 39" AUTOMATIC FLIP SEAT BACKPAN 4 LEG | 1 | 429613013 |
| FOOT, SEAT AUTOMATIC FLIP 4- LEG 39" | 1 | 2216040C1 |
| FOOT, SEAT AUTOMATIC FLIP 39 IN 4 LEG | 2 | 443810001 |
| FOOT, SEAT AUTOMATIC FLIP 4- LEG 39" | 1 | 2216041C1 |
| SUPPORT FLIP SEAT FR BRACKET L | 1 | 2202390C1 |
| SUPPORT FR LH BARRIER AISLE SIDE | 1 | 429168002 |
| SUPPORT FR RIGHT HAND BARRIER AISLE SIDE | 1 | 429168001 |
| SUPPORT FLIP SEAT BRACKET R | 1 | 2202391C1 |
| FR, TUBULAR 39" AUTOFLIP SEAT | 2 | 443910001 |
| PLATE ASSEMBLY ANCHOR SEATBELT SINGLE RIGHT HAND | 1 | 443834002 |
| REINFORCEMENT BAR AUTOMATIC FLIP 39 IN CENTER | 1 | 427673062 |
| PLATE ANCHOR SEATBELT 39 IN AUTOFLIP | 2 | 2218737C1 |
| REINFORCEMENT 39 IN AUTOMATIC FLIP END | 2 | 427673064 |
| REINFORCEMENT BAR AUTOMATIC FLIP 39 IN END | 2 | 427673063 |
