3777733C91
SEAT, LEFT HAND, BUS BODY, 36 BTI 3PT 42OZ PREVAIL BLUE N/ICS
IC Bus
BACK ORDERED
Please contact us for information on lead time
$569.95
$683.94
This truck part is made by IC Bus. We guarantee that all of our parts are from the OEM (original equipment manufacturer), ensuring a proper fit and quality manufacturing.
We honor the warranty provided by the original equipment manufacturer.
RELATED PARTS
SPECIFICATIONS
OEM Description
SEAT, LEFT HAND, BUS BODY, 36 BTI 3PT 42OZ PREVAIL BLUE N/ICS
BILL OF MATERIALS
| Name | Quantity | Part Number |
|---|---|---|
| FR SEAT BASE ASSEMBLY WELDMENT L 39 IN | 1 | 3683851C6 |
| FILM, POLYETHYLENE 36" WIDE | 57 | 3847662C1 |
| SUPPORT DUAL RISER TAIL, R | 1 | 3854734C1 |
| PLYWOOD SEAT BASE CUSHION BO | 1 | 3682036C3 |
| REINFORCEMENT, BUS BODY, WALL RISER, L | 1 | 3769975C1 |
| FRAME, SEAT, BUS BODY , 36 BTI 3PT BACKREST N/ICS | 1 | 4097853C1 |
| BOLT, HEXAGON FLANGE HEAD | 2 | 2229009C1 |
| BOLT HEXAGON FLANGE 3/8-16X4 W/LOCKING PATCH | 2 | 3827492C2 |
| NUT HEXAGON FLANGE 3/8-16 GRADE 8 | 4 | 3836928C1 |
| FOAM, CUSHION SEAT 36" | 1 | 3681474C1 |
| LATCH, SEAT, IMMI | 1 | 3952868C1 |
| LATCH, SEAT, BUS BODY, IMMI | 1 | 3952868C2 |
| CLIP, SEAT CUSHION ROTATION | 2 | 3827500C3 |
| SCREW SCREW, TAPPING PAN HEAD CR | 6 | 24396R1 |
