3589714C91
CASE, TRANSFER W/GEARS 13TKD
Navistar International®
BACK ORDERED
Please contact us for information on lead time
$41,999.95
$50,399.94
This is an oversize product. Additional shipping fees may apply.
This truck part is made by Navistar International®. We guarantee that all of our parts are from the OEM (original equipment manufacturer), ensuring a proper fit and quality manufacturing.
We honor the warranty provided by the original equipment manufacturer.
SPECIFICATIONS
VMRS
025-001-000
OEM Description
CASE TRANSFER CPT W/GEARS*TRAN
Weight
1282.68 lbs
BILL OF MATERIALS
| Name | Quantity | Part Number |
|---|---|---|
| CUP, BEARING | 2 | 1696550C1 |
| BEARING, CUP OUTER WHEEL | 4 | TMJM716610 |
| BEARING, CUP OUTER WHEEL | 4 | 1693255C1 |
| SHAFT, SHIFT TRANSFER CASE | 1 | 2586456C1 |
| SHAFT, MAIN UPPER | 1 | 1681081C1 |
| SHAFT, INTERMEDIATE | 1 | 1681082C1 |
| SPRING, SHIFT LEVER SHAFT | 1 | 588907C1 |
| SPRING, TRANSFER CASE SHIFT LEVER | 1 | 1663137C1 |
| SPRING, OIL PUMP | 1 | 1677664C1 |
| BEARING, CONE OUTER WHEEL BEARING | 4 | 1693280C91 |
| O-RING CLASS 5 3/8" X 1/2" | 1 | 355967R1 |
| PLATE, COVER DECLUTCH | 1 | 588903C1 |
| PLATE, COVER DECLUTCH | 1 | 1681095C1 |
| PLATE, COVER TRANSFER CASE | 1 | 587352C1 |
| PLATE BACKING OIL PUMP | 1 | 1696622C1 |
| SWITCH, INDICATOR | 1 | 1697674C1 |
| VENT, BREATHER | 1 | 1677338C1 |
| BEARING, CUP | 1 | FP742 |
| BEARING, CUP | 1 | 1696552C1 |
| ADAPTER TRANSFER CASE SHIFT | 1 | 588906C1 |
| SPACER, SHIFT SHAFT TUBE | 1 | 587386C1 |
| TUBE, TRANSFER CASE SHIFT CYLINDER | 1 | 587383C1 |
| SPACER, TRANSFER CASE SHIFT CYLINDER | 1 | 1663138C1 |
| BEARING, CONE | 1 | 1696551C1 |
| WASHER, FLAT 5/16" | 10 | 25708R1 |
| WASHER, FLAT | 62 | 25846R1 |
| WASHER INDICATOR LIGHT SWITCH | 1 | 504251C1 |
| WASHER SHIFT SHAFT LOW | 1 | 1681098C1 |
| WASHER, SPECIAL | 1 | 588889C1 |
| WASHER OUTPUT SHAFT | 2 | 587380C1 |
| KEY, WOODRUFF HARDENED | 3 | 2586459C1 |
| BLOCK, SHIFT TRANSFER CASE | 1 | 588892C1 |
| PLATE, SHIFT SHAFT TRANSFER CASE | 1 | 587344C1 |
| COVER, OIL PUMP | 1 | 1681065C1 |
| COVER, REAR SHIFT CYLINDER | 1 | 1681066C1 |
| CUP, BEARING TRANSFER CASE | 1 | 1697859C1 |
| RETAINER, TRANSFER CASE SEAL | 1 | 588846C1 |
| BOLT 7/16" X 1 1/4" | 56 | 70427R1 |
| BOLT 5/16" X 1 1/4" | 4 | 25751R1 |
| BOLT 1/4" X 1/2" | 4 | 25752R1 |
| BOLT 1/4" X 3/4" | 4 | 25222R1 |
| BOLT 7/16" X 1 1/2" | 2 | 80298R1 |
| BOLT BOLT, HEXAGON HEAD 1/4-20UNC X 3 3/4,PHC GRADE | 4 | 26288R1 |
| BOLT, 1/4 X 4-1/2 PHC TYPE 8 | 4 | 26290R1 |
| BRACKET, MOUNTING OIL FILTER | 1 | 1681073C1 |
| WASHER, FELT | 2 | 588887C1 |
| FILTER OIL T/C | 1 | 1681075C1 |
| FITTING, NIPPLE TRANSFER CASE OIL FILTER | 1 | 1697938C1 |
| YOKE, SHIFT DECLUTCH | 1 | 1697338C1 |
| YOKE, SHIFT TRANSFER CASE | 1 | 1681084C1 |
| GASKET TRANSFER CASE OIL SEAL | 2 | 588847C1 |
| GASKET TRANSFER CASE DECLUTCH HOUSING | 1 | 588901C1 |
| GASKET DECLUTCH HOUSING COVER | 1 | 588904C1 |
| GASKET SHIFT BAR HOUSING COVER TRANSFER CASE | 1 | 504240C1 |
| GASKET FRONT INTERMEDIATE SHAFT COVER | 1 | 587343C1 |
| GASKET OUTPUT SHAFT RETAINER | 1 | 587349C1 |
| GASKET TRANSFER CASE COVER | 1 | 587351C1 |
| GEAR COLLAR CLUTCH | 1 | 1697339C1 |
| BEARING, CONE | 1 | 1677598C1 |
| GEAR CLUTCH 33T | 1 | 2586406C1 |
| GEAR INTERMEDIATE TRANSFER CASE | 1 | 1695434C1 |
| GEAR MAIN SHAFT TRANSFER CASE | 1 | 1695435C1 |
| GEAR INTERMEDIATE HELICAL | 1 | 2586412C1 |
| GEAR HELICAL 62T | 1 | 2586413C1 |
| GEAR HELICAL 45T | 1 | 2586414C1 |
| HOUSING, FRONT TRANSFER CASE | 1 | 1696559C1 |
| RING, "O" BUNA-N .489" X .559" | 1 | 2586417C1 |
| RING, "O" TRANSFER CASE | 6 | 1663094C1 |
| RING, "O" TRANSFER CASE | 2 | 1663095C1 |
| NUT, JAM SPECIAL 1 1/4" UNF | 1 | 1697950C1 |
| NUT, FLEXLOCK | 1 | 588890C1 |
| BEARING, CUP AND CONE ASSEMBLY | 1 | 1681062C91 |
| NUT HEXAGON LOCK 1/2-13UNC,CAD | 1 | 9412230 |
| NUT HEXAGON LOCK 1/2-13UNC,CAD | 1 | 359787C1 |
| BOLT, DECLUTCH HOUSING | 6 | 1697668C1 |
| SEAL, OIL AXLE SHAFT FRONT | 1 | 1685669C1 |
| BEARING, CUP AND CONE ASSEMBLY | 1 | 1681063C91 |
| BEARING, CUP AND CONE ASSEMBLY | 2 | 2586397C91 |
| COVER, REAR TRANSFER CASE | 1 | 1696554C1 |
| RETAINER, TRANSFER CASE SEAL | 1 | 2586400C1 |
| RETAINER, BEARING | 1 | 2586401C1 |
| RETAINER, PLANET GEAR | 1 | 2586402C1 |
| RETAINER, TRANSFER CASE SEAL | 1 | 2586403C1 |
| RETAINER, TRANSFER CASE SEAL | 1 | 2586404C1 |
| BOLT 5/16" X 3" | 6 | 25236R1 |
| STOP, PISTON | 1 | 1677318C1 |
| GASKET OIL PUMP | 1 | 1677650C1 |
| GEAR SPEEDOMETER DRIVE 16T | 1 | 1696558C1 |
| GEAR PLANET 20T | 3 | 2586407C1 |
| GEAR INTERNAL 62T | 1 | 2586409C1 |
| GEAR CLUTCH | 1 | 1677614C1 |
| GEAR TRANSFER CASE | 1 | 2586410C1 |
| GEAR, LOCKOUT | 1 | 2586411C1 |
| HOUSING, TRANSFER CASE PLANTETARY | 1 | 2586415C1 |
| HOUSING, TRANSFER CASE | 1 | 2586416C1 |
| NUT, LOCK TRANSFER CASE | 1 | 1663099C1 |
| SCREW, DRIVE TRANSFER CASE | 2 | 596174C1 |
| SEAL, OIL TRANSFER CASE | 1 | 2586420C1 |
| SEAL, OIL TRANSFER CASE | 1 | 2586421C1 |
| RING, SNAP GEAR | 1 | 504218C1 |
| RING, SPACER PLANET PINION | 6 | 2586431C1 |
| RING, SPACER | 6 | 2586432C1 |
| RING, RETAINER TRANSFER CASE | 1 | 2586439C1 |
| PIN | 3 | 2586445C1 |
| SPACER, TRANSFER CASE OUTPUT SHAFT BEARING | 1 | 1696619C91 |
| SHAFT TRANSFER CASE | 1 | 2586453C1 |
| SHAFT, SHIFT POWER TAKE- OFF OUTPUT | 1 | 588908C1 |
| SHAFT TRANSFER CASE | 1 | 2586454C1 |
| SHAFT TRANSFER CASE | 1 | 2586455C1 |
| PUMP, TRANSFER CASE OIL | 1 | 1696621C1 |
| TUBE, SPACER TRANSFER CASE | 1 | 2586457C1 |
| TUBE TRANSFER CASE | 2 | 2586458C1 |
| WASHER, FLAT | 11 | 25710R1 |
| WASHER TRANSFER CASE OUTPUT SHAFT | 1 | 1663131C1 |
| SHIM POWER TAKE- OFF MOUNTING CORAL .030" | 3 | 588849C1 |
| SHIM POWER TAKE- OFF PINK .015" | 1 | 588850C1 |
| SHIM POWER TAKE- OFF MOUNTING BLUE .005" | 2 | 588851C1 |
| SHIM POWER TAKE- OFF MOUNTING RED .002" | 2 | 588852C1 |
| SHIM OIL PUMP TRANSFER CASE | 2 | 1697867C1 |
| SHIM INTERMEDIATE SHAFT .005" | 2 | 1697964C1 |
| SHIM INTERMEDIATE SHAFT .002" | 1 | 1697965C1 |
| SHIM INTERMEDIATE SHAFT .015" | 2 | 1697963C1 |
| SHIM INTERMEDIATE SHAFT .030" | 3 | 1697962C1 |
| SHIM REAR OUTPUT SHAFT .015" | 1 | 1697968C1 |
| SHIM REAR OUTPUT SHAFT .002" | 2 | 1697966C1 |
| SHIM REAR OUTPUT SHAFT .005" | 2 | 1697967C1 |
| SHIM REAR OUTPUT SHAFT .030" | 3 | 1697969C1 |
| PIN POWER TAKE- OFF LOCK | 1 | 588913C1 |
| PISTON, SHIFT CYLINDER | 1 | 588888C1 |
| PISTON, SHIFT | 1 | 1681080C1 |
| RING, SPACER LOWER SHAFT .719" | 1 | 1697961C1 |
| FITTING, DRAIN PLUG 1/4" NPT | 1 | 444618 |
| PLUG, DRAIN | 2 | 582591C1 |
| PLUG 1" X 1-1/8" | 1 | 172545 |
| PLUG, FILLER | 2 | 582592C1 |
