3675092C91
CASE, TRANSFER W/GEARS
Navistar International®
BACK ORDERED
Please contact us for information on lead time
$8,199.95
$9,839.94
This truck part is made by Navistar International®. We guarantee that all of our parts are from the OEM (original equipment manufacturer), ensuring a proper fit and quality manufacturing.
We honor the warranty provided by the original equipment manufacturer.
SPECIFICATIONS
VMRS
025-001-000
OEM Description
CASE TRANSFER CPT W/GEARS TRA
BILL OF MATERIALS
| Name | Quantity | Part Number |
|---|---|---|
| NUT, LOCK TRANSFER CASE | 3 | 1663098C1 |
| GEAR INTERMEDIATE 20T | 3 | 596169C1 |
| BEARING (CONE), TRANSFER CASE | 6 | 1663076C91 |
| BEARING, BALL | 6 | SKF382A |
| BEARING, BALL | 6 | FP382A |
| GEAR FRONT OUTPUT TRANSFER CASE | 1 | 1663091C1 |
| WASHER, THRUST TRANSFER CASE OUTPUT SHAFT | 1 | 1663133C1 |
| BEARING, CONE | 3 | 1663077C91 |
| BEARING CUP | 3 | SKF453X |
| BEARING CUP | 3 | 50320R1 |
| NUT, LOCK TRANSFER CASE | 3 | 1663100C1 |
| WASHER BETWEEN BEARINGS AND YOKES | 1 | 1681293C1 |
| RETAINER, TRANSFER CASE OUTPUT SHAFT BEARING | 1 | 596158C1 |
| GASKET TRANSFER CASE COVER | 1 | 596165C1 |
| SEAL, OIL REAR OUTPUT TRANSFER CASE | 1 | 596175C1 |
| RETAINER, TRANSFER CASE REAR OUTPUT SEAL | 1 | 1663082C1 |
| GASKET REAR OUTPUT SEAL RETAINER | 1 | 596167C1 |
| PLATE, COVER TRANSFER CASE | 1 | 596189C1 |
| CUP, BEARING | 1 | 286648R1 |
| BEARING | 1 | FP4595 |
| BEARING | 1 | 286650R91 |
| SPACER, REAR OUTPUT BEARING | 1 | 596194C1 |
| BOLT 7/16" X 1 1/4" | 44 | 70427R1 |
| GEAR REAR OUTPUT TRANSFER CASE | 1 | 596168C1 |
| RING, SPLIT RETAINER TRANSFER CASE | 3 | 596179C1 |
| SHAFT, REAR OUTPUT TRANSFER CASE | 1 | 1677284C1 |
| BEARING, BALL | 1 | 392679R91 |
| CUP, BEARING | 1 | 170234R1 |
| HOUSING, TRANSFER CASE | 1 | 2508905C1 |
| WASHER INTERMEDIATE SHAFT | 1 | 1677286C1 |
| NUT, LOCK BEARING | 1 | 1681291C1 |
| YOKE, SHIFT MAIN SHAFT TRANSFER CASE | 1 | 1663086C1 |
| SEAL, OIL MAIN AND OUTPUT TRANSFER CASE | 2 | 1663101C1 |
| CAP TRANSFER CASE INTERMEDIATE REAR | 1 | 1663081C1 |
| GASKET REAR INTERMEDIATE RETAINER | 1 | 1663087C1 |
| NUT, LOCK TRANSFER CASE | 1 | 1663097C1 |
| WASHER TRANSFER CASE INTERMEDIATE SHAFT | 1 | 1663132C1 |
| BEARING, CONE | 1 | 895366C1 |
| BEARING, CONE | 1 | 895102C91 |
| GEAR HELICAL TRANSFER CASE 34T | 1 | 596171C1 |
| YOKE, SHIFT INTERMEDIATE SHAFT TRANSFER CASE | 1 | 596164C1 |
| SHAFT, INTERMEDIATE TRANSFER CASE | 1 | 1677285C1 |
| SHAFT, SHIFT TRANSFER CASE | 1 | 596178C1 |
| RETAINER, OUTPUT SHAFT BEARING | 1 | 1663084C1 |
| TUBE, SHIFT CYLINDER | 1 | 596114C1 |
| BOLT | 4 | 26291R1 |
| GEAR INTERMEDIATE TRANSFER CASE | 1 | 1663089C1 |
| BOLT 1/4" X 1/2" | 8 | 25752R1 |
| PLATE, SHIFT SHAFT TRANSFER CASE | 2 | 504248C1 |
| GASKET OUTPUT SHAFT BEARING RETAINER | 2 | 496345C1 |
| CAP INTERMEDIATE FRONT | 1 | 1677283C1 |
| VENT AIR | 1 | 1681292C1 |
| GASKET SHIFT BAR HOUSING COVER TRANSFER CASE | 2 | 504240C1 |
| RETAINER, TRANSFER CASE INPUT SHAFT | 1 | 1663078C1 |
| SPACER, TRANSFER CASE MAIN SHAFT BEARING .2" | 1 | 1663122C1 |
| PLUNGER INDICATOR LIGHT SWITCH | 1 | 504250C1 |
| CUP, BEARING | 1 | FP59412 |
| CUP, BEARING | 1 | 65120H |
| SCREW, SET SHIFT YOKE | 3 | 504247C1 |
| YOKE, SHIFT FRONT DRIVE TRANSFER CASE | 1 | 1663085C1 |
| ADAPTER SHIFT CYLINDER | 2 | 588885C1 |
| SPRING, SHIFT SHAFT | 2 | 594922C1 |
| GEAR MAIN TRANSFER CASE | 1 | 1663090C1 |
| STOP, PISTON | 2 | 1677318C1 |
| SHAFT, MAIN TRANSFER CASE | 1 | 1663129C1 |
| SHAFT, SHIFT FRONT TRANSFER CASE | 1 | 596188C1 |
| GEAR MAIN LOW TRANSFER CASE | 1 | 1663088C1 |
| BEARING (CONE), TRANSFER CASE | 2 | 392619C91 |
| O-RING CLASS 5 3/8" X 1/2" | 2 | 355967R1 |
| SCREW, DRIVE TRANSFER CASE | 2 | 596174C1 |
| PLUG, FILLER AXLE HOUSING | 1 | 1693233C1 |
| PLUG, OIL LEVEL | 1 | 582590C1 |
| PLUG, DRAIN | 1 | 582591C1 |
| PLUG, HEAT INDICATOR | 1 | 1695005C1 |
| YOKE, END SPL 140 SERIES | 2 | 2592314C1 |
| WASHER TRANSFER CASE 3/8" | 18 | 596118C1 |
| YOKE, END SPL 100 SERIES | 1 | 2592313C1 |
| CUP, BEARING | 1 | 1663075C1 |
| SWITCH, LIGHT BACK UP LIGHT | 1 | 461778C1 |
| TRANSMITTER, ELECTRONIC SPEEDOMETER W/INTEGRAL PACKARD METRI- PACKAGE CONNECTOR | 1 | 3528003C1 |
| WASHER, FELT | 2 | 588887C1 |
| RETAINER, INPUT SHAFT BEARING | 1 | 2502484C1 |
| PISTON, SHIFT CYLINDER | 2 | 588888C1 |
| RING, "O" TRANSFER CASE | 2 | 1663095C1 |
| WASHER, SPECIAL | 2 | 588889C1 |
| BOLT 1/4" X 4" | 4 | 26289R1 |
| BLOCK, SHIFT TRANSFER CASE | 2 | 588892C1 |
| RING, "O" TRANSFER CASE | 6 | 1663094C1 |
| SHAFT, FRONT OUTPUT TRANSFER CASE | 1 | 1663127C1 |
| TUBE, DECLUTCH SHIFT CYLINDER | 1 | 596190C1 |
| NUT, FLEXLOCK | 2 | 588890C1 |
| WASHER INDICATOR LIGHT SWITCH | 1 | 504251C1 |
CROSS REFERENCES
- FABCO 873-4009-016-SN
- FABCO 873-4009-016-SN
- FABCO 8734009016SN
- FABCO 8734009016SN
RECOMMENDED PARTS
* This information is provided as is and may be out of date. Please contact us or the manufacturer to verify warranty
coverage.
