This truck part is made by Cummins®. We guarantee that all of our parts are from the OEM (original equipment manufacturer), ensuring a proper fit and quality manufacturing.
We honor the warranty provided by the original equipment manufacturer.
DESCRIPTION
The Centinel Upfit Kit, with part number 3806163, is a specialized accessory designed for heavy-duty trucks. This kit provides an innovative solution for the prevention of engine idle shutdowns while still maintaining compliance with local regulations. The kit includes a control module that interfaces with the truck's ECM to monitor and regulate engine uptime. It also comes equipped with an easy-to-use interface that allows for customization of settings according to individual needs. This upfit kit ensures smooth engine operation and prolongs the lifespan of critical components by preventing unnecessary wear-and-tear caused by frequent starting and stopping.
SPECIFICATIONS
Service Part Topic
04T0-9
Hazardous Material
Non-Hazardous (NOI, ICE/Auto)
Package Dimensions
23.0 x 16.3 x 15.25 in
Weight
55 lb
BILL OF MATERIALS
| Name | Quantity | Part Number |
|---|---|---|
| Clip | 1 | 68152 |
| Fuel Tank Breather | 1 | 68982 |
| Lock Nut | 1 | 555273 |
| Hexagon Head Cap Screw | 1 | 3099030 |
| Hose Cover | 2 | 3099031 |
| Plain Hose Coupling | 1 | 3099059 |
| Elbow Hose Coupling | 1 | 3099060 |
| Male Union | 1 | 3099066 |
| Male Union | 1 | 3099067 |
| Plain Hose | 2 | 3099072 |
| Plain Hose | 1 | 3099074 |
| Hose Cover | 1 | 3099076 |
| Valve Bracket | 1 | 3170777 |
| Mounting Spacer | 1 | 3170789 |
| Valve Brace | 1 | 3170795 |
| Plain Hose Coupling | 1 | 3170797 |
| Elbow Hose Coupling | 5 | 3170802 |
| Male Union | 1 | 3170805 |
| Male Union | 1 | 3170807 |
| Male Union | 1 | 3170808 |
| Male Connector | 1 | 3170812 |
| Male Connector | 1 | 3170813 |
| Regular Hexagon Nut | 2 | 3201128 |
| Lubricating Oil Filter Element | 4 | 3313305 |
| Oil Bypass Filter Element | 2 | 3889311 |
| Sealing Washer | 1 | 3963983 |
| Plain Washer | 4 | S602 |
| Plain Washer | 1 | S622 |
| Grease Fitting | 1 | ST4342 |
RECOMMENDED PARTS
* This information is provided as is and may be out of date. Please contact us or the manufacturer to verify warranty
coverage.
* Variable geometry turbocharger and electronic actuator repairs are not eligible to be claimed as over-the-counter under New or ReCon parts warranty for parts installed after October 1, 2018.
* Diesel Oxidation Catalyst (DOC), Diesel Particulate Filter (DPF), Selective Catalyst Reduction (SCR) catalyst, and Electronic Control Module (ECM) repairs are not eligible to be claimed as over-the-counter under New or ReCon parts warranty for parts installed after January 1, 2020.
* These restrictions are only applicable to New parts and ReCon parts coverages for the components listed above sold to a customer in the US or Canada. All other coverages are excluded. All other regions are excluded.
* Variable geometry turbocharger and electronic actuator repairs are not eligible to be claimed as over-the-counter under New or ReCon parts warranty for parts installed after October 1, 2018.
* Diesel Oxidation Catalyst (DOC), Diesel Particulate Filter (DPF), Selective Catalyst Reduction (SCR) catalyst, and Electronic Control Module (ECM) repairs are not eligible to be claimed as over-the-counter under New or ReCon parts warranty for parts installed after January 1, 2020.
* These restrictions are only applicable to New parts and ReCon parts coverages for the components listed above sold to a customer in the US or Canada. All other coverages are excluded. All other regions are excluded.
